Switching off:
When switching off, follow the same procedure as when switching on the receiver.
1. Place the red mark on the transmitter against the red mark on the receiver - the green
indicaton light will illuminate, followed by the red indication light.
2. When the red light comes on, move the transmitter away from the receiver. The receiver
will stop flashing.
IMPORTANT: When switching on/off, simply hold the transmitter target against the
receiver target for approximately 1 second. If you hold the targets together for more
than 5 seconds, the receiver will go into transmitter-receiver pairing mode. This mode is
indicated by the alternating flashing of the green and red indication lights. If this occurs,
follow the steps in the 7.4 Pairing the transmitter with the receiver.

7.4 Pairing the transmitter with the receiver

In order for the transmitter (handheld device) to communicate with the receiver (collar), they
must be paired together. When you buy a set of d-control receiver and transmitter, there is
no need to pair - the set is already paired from the factory. Pairing is required when you buy
another collar or a new transmitter. Up to six collars can be paired to one transmitter and two
transmitter can be paired to one collar at the same time.
First, you must set the desired number of positions on the transmitter for pairing the
collars:
1. Simultaneously long press the
will flash on the display.
2. Use the /
want to use on the transmitter.
3. Confirm your selection by short pressing the
Use the buttons
1 to 6). Now you can start pairing the collars with the transmitter. The collar you want to pair
must be switched off.
4. Use the /
pair the collar.
5. Place the red mark on the bottom of the transmitter against the red mark of the receiver
for 5 seconds (similar to switching on the receiver - see the illustration in chapter 7.3). The
red indication light will come on, followed by the green indicator light.
6. After 5 seconds, the green and red indication lights will flash alternately.
7. Now press the
To pair other collars, simply use the
control and repeat the procedure from step 5.
NOTE: The collar will only stay in pairing mode for 15 seconds. If the green and red
lights stop flashing alternately before you press the
pairing procedure - point 5 to 7. Pairing can be done at a limited distance between the
transmitter and the collar (up to approximately 3 m).
7.5 Pairing a second transmitter to one receiver
On one receiver can be paired 2 transmitters (remote controls) and one receiver can have
two positions on one transmitter. The collar to which you want to pair the second transmitter
must be switched on.
1. Use the /
30
and
buttons to set the desired number of positions for pairing the collars you
/ to select between collar positions (depending on the settings - collar
buttons on the remote control to select the position to which you want to
button on the trasmitter.
buttons to select the position on the transmitter to which you want to pair
buttons and the currently set number of positions
button.
/ buttons to select a different position on the remote
button , you must repeat the
