6.2 Checking the battery level in the transmitter

The battery status of the transmitter is indicated by the
battery symbol on the LCD display.
6.3 Turning on/off the transmitter
Press the button for 1 second to switch the transmitter
on or off.

7. RECEIVER PREPARATION

7.1 Charging the receiver

The Edge ONE receiver contains a Li-Pol rechargeable battery. The battery must be charged
before using the device for the first time.
1. Remove any dirt from the charging contacts. Connect the mains cable to the device using
the clip. The tabs on the charging clip must fit into the
slots on the collar housing.
2. Connect the mains cable to a 5 to 5.5 V DC charging
adapter (not included in the scope of delivery), which
you then connect to the mains.
3. The orange indicator light on the device lights up
(charging time is approx. 2 hours).
4. When the charging process is complete, the orange
indicator light goes out.
WARNUNG: Charge the battery in an environment with a temperature between 0° and
40°C. To charge, use a charging adapter with a voltage between 5 and 5.5 V DC or the
original 5.2 V mains adapter offered by the manufacturer as an optional accessory. Using
an adapter with a higher voltage could damage the electronic collar.
7.2 Checking the battery level in
the receiver
The battery indication lights (LEDs)
on the side of the receiver are used to
check the battery in the receiver (see
Figure 3/4 on page 2).
If the red LED flashes, the collar is
collar is empty and needs to be recharged. Do not leave the Edge ONE in a discharged
in a discharged state for an extended period of time. The battery could be damaged.

7.3 Turning on/off receiver

A magnetic switching system is used to switch the
receiver on/off, which is activated by attaching a magnet.
The magnet is located at the bottom of the transmitter
marked with a red target
Switching on:
1. Place the red mark on the transmitter against the red
mark on the receiver - the red indication light will
illuminate, followed by the green indication light.
2. When the green light comes on, move the transmitter
away from the receiver. The green light will start
flashing.
Battery status
100%
35%
20%
.
EN
Battery status
100%
60%
30%
10%
Green indicator light
Simultaneous green and red
indicator light
Red indicator light
Transmitter
Receiver
