SET-UP AND INSTALLATION
RT890E
BOTTOM BOOM NOSE
SHEAVES
TO MAIN HOIST
HOOK BLOCK DEAD END
UPPER BOOM NOSE SHEAVE
AUXILIARY NOSE
HOOK BLOCK SHEAVES
6267-1
TO MAIN HOIST
BOTTOM BOOM NOSE SHEAVES
UPPER BOOM NOSE
SHEAVE
BOOM NOSE DEAD END
HOOK BLOCK SHEAVES
6267-2
FIGURE 4-4
