LUBRICATION
15. Fuel Strainer
Change strainer every 500 hours or 6 months
16. Turntable Gear Box
Lube Type - SSGL-5
NOTE: Remove one valve to equalize the pressure before
checking the swing gearbox oil level. This will keep
the oil from pushing out.
Lube Interval - Check and fill every 50 hours. Drain and
fill after first 250 hours and every 500 hours or 12
months thereafter.
Lube Amount - Capacity - 5.4 liters (5.7 quarts)
Application - Fill mark on dipstick.
17. Turntable Gear and Drive Pinion
Lube Type - EP-OGL
Lube Interval - 500 hours or 6 months
Lube Amount - Coat all teeth
Application -Spray on
18. Turntable Bearing
Lube Type - EP-MPG
Lube Interval - 500 hours or 6 months
Lube Amount - Until grease extrudes the whole
circumference of the bearing.
Application - 2 grease fittings at the front of the turntable.
Rotate the turntable 90° and apply grease to fittings.
Continue rotating 90° and grease the fittings until the
whole bearing is greased.
19. Hose Rollers - Turntable
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months
Lube Amount - Until grease extrudes
Application - 2 grease fittings
20. Cab Tilt Cylinder Pivot Pins
Lube Type - EP-MPG
Lube Interval - 500 hours or 3 months
Lube Amount -Until grease extrudes
Application - 2 grease fittings
5-8
21. Pillow Block
Lube Type - EP-MPG
Lube Interval - 500 hours or 3 months
Lube Amount - Until grease extrudes
Application - 2 grease fittings
22. Outrigger Beams
Lube Type - EP-OGL
Lube Interval - 500 hours or 6 months
Lube Amount - Spray lubricant on bottom of outrigger
beams.
Application - Spray on
23. Jack Cylinder Support Tubes
Lube Type - EP-OGL
Lube Interval - 500 hours or 6 months
Lube Amount - Spread lubricant on ID of jack cylinder
support tubes before installing jack cylinders.
Application - Spray on
24. Hook Block Swivel Bearing
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months
Lube Amount - Until grease extrudes
Application - 1 grease fitting
25. Hook Block Sheaves
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months
Lube Amount - Until grease extrudes
Application - 1 grease fitting per sheave
(5 fittings total - 80 ton)
26. Headache Ball
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months
Lube Amount -Until grease extrudes
Application - 1 grease fitting
