OPERATING CONTROLS AND PROCEDURES
Item
1 Defroster Switch
2 Hand Throttle Control Knob
3 Ignition Switch
4 Voltmeter
5 Transmission Oil Temperature Gauge
6 Heat Control Knob
7 Fan Control Switch
8 Park Brake Control Switch
9 Air Conditioner Control Switch
10 Swing Brake Control Switch
11 Differential Lock Control Switch (Optional)
13 Drive Axle Selector Switch
14 Cab Tilt Switch
15 Outrigger Control Switches
16 Work Light Switch
17 Headlights Switch
18 Boom Lights Switch (Optional)
19 Hazard Lights Switch
20 Hose Reel Brake On Indicator
21 Fuel Gauge
22 Engine Diagnostics Test Mode Switch
23 Engine Diagnostics Idle Switch
24 Engine Coolant Temperature Gauge
25 Tachometer
26 Crane Function Power Switch
27 Outrigger Extend/Retract Switch
Load Moment Indicating (LMI) and Work
28
Area Definition System Control Panel
Auto/Manual Boom Telescope Section
29
Select Switch
Center/Inner Mid Boom Telescope Section
30
Select Switch
31 Rear Steer Control Switch
Auxiliary Hoist Speed Selector Switch
32
(Optional)
33 Swing Control Lever
Turn Signal Lever and Windshield Wiper/
34
Washer Controls
35 Bubble Level Indicator
3-4
Description Item Description
36 Cab Circulating Fan
37 Electrical System Diagnostics Indicator
38 Swing Brake Pedal
39 Telescope Control Foot Pedal
40 Windshield Wiper
41 Defroster Fan
42 Service Brake Pedal
43 Spotlight (Optional)
44 Foot Throttle Pedal
45 Transmission Shift Lever
46 Circuit Breaker Panel
47 Pin Swing Lock Control (Pin Type)
48 Hoist Rotation Indicators
49 Main Hoist Control Lever
360 Degree Swing Lock Control (Positive
50
Lock Type)
51 Main Hoist Speed Selector Switch
Engine and System Diagnostic Connector
52
(Not Shown)
53 Luffing Jib Raise/Lower Switch (Optional)
54 Luffing Jib On/Off Switch (Optional)
55 Seat Switch (Not Shown)
56 Cab Dome Light
57 Fire Extinguisher
58 Boom Lift Control Lever
59 12 VDC Accessory Outlet
60 Auxiliary Hoist Control Lever
61 Horn
62 Turn Signal Indicators
63 Rear Wheels Not Centered
64 Hoist Third Wrap Indicator (Optional W/CE)
65 Engine Stop Indicator
66 Engine Warning Indicator
67 Engine Service Indicator
68 Wait To Start Indicator
69 Low Brake Pressure Indicator
70 Transmission Service Indicator (XMSN)
71 Water In Fuel Indicator
