RT890E
Item Description
1 Steering Cylinder Pivot Pins
2 King Pins (Upper and Lower)
3 Fifth Wheel Pivots
4 Lockout Cylinder Pivot Pins
5 Tie Rod Pivot Pins
6 Differentials
7 Planetary Hubs and Wheel Bearings
Engine Crankcase (Cummins QSB-
8
275) with Filter
9 Transmission and Torque Converter
10 Engine Cooling System (Cummins)
11 Coolant Strainer (Cab Heater)
12 Air Cleaner Filter
13 Fuel Filter
14 Driveline - Slip Joints
15 Fuel Strainer
16 Turntable Gearbox
17 Turntable Gear and Drive Pinion
18 Turntable Bearing
19 Hose Rollers - Turntable
20 Tilt Cylinder Pivot Pins
21 Pillow Block
22 Outrigger Beams
Item Description
23 Jack Cylinder Support Tubes
24 Hook Block Swivel Bearing
25 Hook Block Sheaves - 80 Ton
26 Headache Ball
27 Telescope Cylinder Wear Pads
Internal Side and Bottom Wear Pads -
28
Inner Sections
29 Boom Section Upper Wear Pads
Boom Section Lower and Upper
30
Wear Pads
31 Extend Cable Sheave
32 Retract Cable Sheave
33 Boom Pivot Shaft
34 Upper Boom Nose Sheave
35 Lower Boom Nose Sheave
36 Hose Rollers - Boom
37 Auxiliary Boom Nose Sheave
38 Mast Sheave
39 Boom Extension Sheaves
40 HP30-18G Main Hoist
41 HP30-18G Auxiliary Hoist
42 Hydraulic Tank
43 Hydraulic Filter
LUBRICATION
5
5-5
