Evaluation Board User Guide

Bill of Materials

ITEM QTY REFERENCE
REQUIRED CIRCUIT COMPONENTS
1 4 C5, C6, C8, C57
2 1 C7
3 2 C14, C22
C15, C23, C55,
4 4
C56, C71, C72
5 2 C17, C25
C36, C37, C45,
6 2
C46
7 2 C53, C54
8 3 C58, C59, C64
9 1 L1
10 1 L2
R11, R12, R16,
11 6
R18, R23, R25
R2, R3, R4, R5,
12 8
R6, R7, R8, R9
13 1 R19
14 1 R20
15 1 U1
ADDITIONAL EVALUATION BOARD CIRCUIT COMPONENTS
1 1 C1
2 1
C2
3 1 C3
4 1
C4
5 0
C16, C24
6 0 C19, C20, C27, C28
7 2
C29, C30
8 1 C31
9 2
C32, C33
10 2
C34, C35
11 4
C38, C39, C40, C41
12 2 C42, C44
analog.com
PART DESCRIPTION
CAP., 10µF, X6S, 10V, 10%, 0603
CAP., 1µF, X6S, 16V, 10%, 0402
CAP., 0.1µF, X7R, 25V, 10%, 0402
CAP., 100µF, X5R, 6.3V, 10%, 1206
CAP., 10µF, X5R, 10V, 10%, 0603
CAP., 1µF, X5R, 35V, 10%, 0402
CAP., 4.7µF, X6S, 25V, 10%, 0603
CAP., 0.1µF, X6S, 25V, 10%, 0201
IND., 0.4µH, 25.1A, 2.7mΩ
IND., 0.9µH, 19.7A, 5.2mΩ
RES., 0Ω, 1/10W, 0603
RES., 10kΩ, 1%, 1/10W, 0603
RES., 51.1kΩ, 1%, 1/10W, 0603
RES., 107kΩ, 1%, 1/10W, 0603
IC, REGULATOR, LQFN-36
CAP., 1µF, X5R, 50V, 10%, 0603
CAP., 100pF, C0G/NP0, 25V, 5%, 0603
CAP., 100µF, ALUM, 35V, 20%, SMD
CAP., 4.7µF, X7R, 10V, 10%, 0805
CAP., OPTION, 7343
CAP., OPTION, 0603
CAP., 0.01µF, X5R, 25V, 10%, 0603
CAP., 0.1µF, X7R,10V, 20%, 0603
CAP., 1µF, X5R, 10V, 10%, 0603
CAP., 0.01µF, X5R, 50V,10%, 0603
CAP., 0.1µF, X7R,50V,10%, 0402
CAP., 10µF, X5R, 50V, 10%,1210
EVAL-LT7184S-AZ
MANUFACTURER/PART NUMBER
MURATA, ZRB18AC81A106KE01L
MURATA, GRM155C81C105KE11D
MURATA, GRM155R71E104KE14
MURATA, GRM31CR60J107KE39L
AVX, 0603ZD106KAT2A
MURATA, GRM155R6YA105KE11D
MURATA, GRM188C81E475KE11D
Taiyo Yuden, TMK063C6104KP-F
COILCRAFT, XGL5030-401MEC
COILCRAFT, XGL5030-901MEC
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW060351K1FKEA
VISHAY, CRCW0603107KFKEA
ANALOG DEVICES, LT7184SRV#PBF
AVX, 06035D105KAT2A
AVX, 06033A101JAT2A
PANASONIC, EEHZK1V101XP
AVX, 0805ZC475KAT2A
AVX, 06033D103KAT2A
AVX, 0603ZC104MAT2A
AVX, 0603ZD105KAT2A
AVX, 06035D103KAT2A
MURATA, GCM155R71H104KE02D
TDK, C3225X5R1H106K250AB
Rev 0 8 of 14
