Evaluation Board User Guide
ITEM QTY REFERENCE
39 2 R70, R72
40 1 R73
41 1 U2
42 2 U3, U5
43 1 U4
HARDWARE: FOR EVALUATION BOARD ONLY
1 6 E1-E6
2 13 E7-E19
3 6 J1-J6
4 1 J8
5 1 J9
6 1 J10
7 3 J11-J13
8 4 JP1-JP4
9 4 MH1-MH4
10 2 SW1, SW2
11 4 XJP1-XJP4
analog.com
PART DESCRIPTION
RES.,1kΩ,1%,1/10W,0603
RES., 470kΩ, 5%, 1/10W, 0603
IC, EEPROM, 2Kb (256x8), TSSOP-8
IC, IDEAL DIO, 10DFN
IC, LDO, TSOT23-5
TEST POINT, TURRET, 0.064"
TEST POINT, TURRET, 0.094"
CONN., BANANA JACK, FEMALE
CONN., HDR, MALE, 2x6 ,2mm
CONN., HDR, MALE, 2x7, 2mm
CONN., HDR, FEMALE, 2x7, 2mm
CONN., BNC, 50Ω
CONN., HDR, MALE,1x3,2mm
STANDOFF, NYLON, SNAP-ON,0.50"
SWITCH, SLIDE, DPDT, 0.3A,
6VDC, PTH
CONN., SHUNT, FEMALE, 2 POS,
2mm
EVAL-LT7184S-AZ
MANUFACTURER/PART NUMBER
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW0603470KJNEA
Microchip, 24LC025-I/ST
ANALOG DEVICES, LTC4413EDD#PBF
ANALOG DEVICES, LT1761ES5-3.3#TRPBF
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
AMPHENOL, 98414-G06-12ULF
MOLEX, 0877601416
SULL. CONN. SOLU., NPPN072FJFN-RC
AMPHENOL RF, 112404
Wurth Elektronik, 62000311121
KEYSTONE, 8833
C&K, JS202011CQN
WÜRTH ELEKTRONIK, 60800213421
Rev 0 10 of 14
