Evaluation Board User Guide
ITEM QTY REFERENCE
13 1 C43
C50, C51, C52,
14 5
C78, C79
C60, C61, C62,
15 0 C63, C74, C75,
C76, C77
C65, C67, C69,
16 0
C70
17 0 C66, C68
18 1 C73
19 0 D1, D2
20 2 D4, D5
21 3 D6, D7, D8
22 1 FB1
23 1 L3
24 3 Q2, Q3, Q5
25 1 Q4
R1, R14, R35,
26 5
R38, R41
27 3 R37, R39, R56
R13, R15, R21,
R22, R24, R26,
R27, R28, R33,
28 0 R34, R36, R40,
R42, R43, R49,
R50, R62, R63,
R67
29 0 R29, R30
30 2 R44, R45
31 2 R46, R61
32 0 R48
R51, R52,
33 5
R64, R65, R66
34 1 R53
35 0 R54
36 1 R57
37 1 R68
38 2 R69, R71
analog.com
PART DESCRIPTION
CAP., 1µF, X5R, 50V, 10%, 0603
CAP., 4.7µF, X5R, 25V, 10%, 0603
CAP., OPTION, 0805
CAP., OPTION, 1206
CAP., OPTION, 1210
CAP., 22µF, X5R, 16V, 10%, 1206
DIODE, OPTION, SOD-323
LED, GREEN, DIFFUSED, 0603
LED, RED, DIFFUSED,0603
FERRITE BEAD, 100Ω@100MHz, 1812
IND., 0.47µH, 6.8A, 14mΩ
MOSFET, N-CH, SOT-23-3
MOSFET, N-CH, DPAK
RES., 0Ω,1/10W,0603
RES.,10kΩ,1%,1/10W,0603
RES., OPTION, 0603
RES., OPTION, 2512
RES., 10Ω, 5%,1/10W, 0603
RES., 4.99kΩ, 1%, 1/10W, 0603
RES., OPTION, 1206
RES., 866Ω, 1%, 1/10W, 0603
RES., 0Ω, 1W, 2010
RES., OPTION, 2010
RES., 10mΩ, 1%, 3W, 2512
RES., 100kΩ, 1%, 1/10W, 0603
RES., 3.9kΩ, 1%, 1/10W, 0603
EVAL-LT7184S-AZ
MANUFACTURER/PART NUMBER
TDK, CGA3E3X5R1H105K080AB
TDK, C1608X5R1E475K080AC
AVX, 1206YD226KAT2A
BROADCOM INC., HSMG-C190
BROADCOM INC., HSMH-H190
WÜRTH ELEKTRONIK, 74279226101
WÜRTH ELEKTRONIK, 744373240047
VISHAY, 2N7002K-T1-GE3
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW060310R0JNEA
VISHAY, CRCW06034K99FKEA
VISHAY, CRCW0603866RFKEA
VISHAY, CRCW20100000Z0EFHP
SUSUMU, KRL6432E-C-R010-F-T1
YAGEO, RC0603FR-07100KL
VISHAY, CRCW06033K90FKEA
