Technical Data; Specification - LOGICDATA COSMO SYDNEY Original Instructions Manual

9. TECHNICAL DATA

PROPERTY
Rated input voltage/current
Type / product weight /
mattress size
Ambient conditions
Maximum load
Duty cycle
Ambient conditions during
transport and storage
Ambient conditions during
operations
Noise
NOTICE
The permitted maximum load is dependent on input voltage. At the lower end of the input voltage range,
maximum load may be reduced. Contact LOGICDATA for additional technical data info.
* For use in prefabricated bed frame

SPECIFICATION

EU: 230 V/1,8 A | US: 110 V/2.2 A
King Cal. King
66 kg (146 lbs) 65 kg (143 lbs)
1 930 x 1 830 x
2 030 mm 2 130 mm
(76" x 80") (72" x 84")
Super King King
65 kg (143 lbs) 60 kg (132 lbs)
1 800 x 1 600 x
2 000 mm 2 000 mm
(71" x 78.5") (63" x 78.5")
EU Small EU Single
38,3 kg 40,1 kg
(84.4 lbs) (88.4 lbs)
780 x 880 x
1 960 mm 1 960 mm
(30.7" x 77.2") (34.6" x 77.2")
EU Double Queen*
49,6 kg 51,9 kg
(109.3 lbs) (114.4 lbs)
1 380 x 1 470 x
1 960 mm 2 000 mm
(54.3" x 77.2") (57.9" x 78.7")
Indoor use only
315 kg (700 lbs) evenly distributed
3.5 min On / 18 min Off
Temperature between -35 °C and 80 °C. Temperature over 50 °C only for periods not
exceeding 72 h. Maximum relative humidity between 95% and 5% (lower allowed).
Temperature between 5 °C and 40 °C. Maximum relative humidity between 95% and
68% (lower allowed).
<60 dBA
COSMO SYDNEY ADJUSTABLE BED FRAME – ORIGINAL INSTRUCTIONS // 27
Queen Full
56 kg (123 lbs) 52 kg (115 lbs)
1 520 x 1 370 x
2 030 mm 1 910 mm
(60" x 80") (54" x 75")
Double Single
54 kg (119 lbs) 42 kg (93 lbs)
1 400 x 900 x
2 000 mm 2 000 mm
(55" x 78.5") (35.5" x 78.5")
Single
EU Small Double
41,9 kg 46 kg
(92.4 lbs) (101.4 lbs)
980 x 1 180 x
1 960 mm 1 960 mm
(38.6" x 77.2") (46.5" x 77.2")
EU King Super King*
53,2 kg 57 kg
(117.3 lbs) (125.7 lbs)
1 580 x 1 775 x
1 960 mm 2 000 mm
(62.2" x 77.2") (69.9" x 78.7")
Twin XL
43 kg (95 lbs)
970 x
2 030 mm
(38" x 80")
Small Single
40 kg (88 lbs)
800 x
2 000 mm
(31.5" x 78.5")
Full Small*
48 kg
(105.8 lbs)
1 315 x
1 872 mm
(51.8" x 73.7")
EU Grand King
57,5 kg
(126.8 lbs)
1 780 x
1 960 mm
(70.1" x 77.2")
