FACTORY RESET

A Factory Reset restores the Bed Frame to the same state as before first use. Any memory positions you have
stored will be deleted and replaced with the pre-set memory positions. To perform a Factory Reset:
1. Press and hold the Foot DOWN and Head DOWN buttons for 10 seconds.
2. When the reset is complete, the Control Box will click twice.
3. Release the buttons.
To perform a Reference Drive after the Factory Reset, only release one of the DOWN buttons. This will start
the Drive automatically.
MOVING THE BED FRAME TO A SAVED MEMORY POSITION
Proceed as follows to move the Bed Frame to a saved Memory Position:
1. Press (in Europe: Press and Hold) the Memory Position Button for the Memory Position
you wish to move to, then release.
2. Wait for the Bed Frame to move to the saved Memory Position.
MOVING THE BED FRAME TO THE SLEEPING POSITION
The Sleeping Position is the Bed Frame's lowest position. While in the Sleeping Position, all Platforms are
horizontal. Proceed as follows to move the Bed Frame to the Sleeping Position:
1. Press (in Europe: Press and Hold) the Sleeping Position Button, then release.
2. Wait for the Bed Frame to move to the Sleeping Position.

ACTIVATING THE CHILD LOCK

Always activate the Child Lock when children are near the Bed Frame. Proceed as follows:
1. Press and hold the Head UP and Foot UP Buttons for at least 6 seconds.
2. The LED will flash 3 times to confirm. Test the Remote Control to check that Child Lock
has been activated.
To disable Child Lock, repeat the steps above.
If you remove the batteries from the Remote Control, the Child Lock will be deactivated automatically If you try
to operate the Bed Frame while the Child Lock is activated, the LED will flash 6 times.
COSMO SYDNEY ADJUSTABLE BED FRAME – ORIGINAL INSTRUCTIONS // 21
