Alternative B (using double click automatic function)
Note: If the double click function is available depends on the
configuration of your control box.
1.
Double-click the desired position button (e.g. 2)
2. The desk automatically moves to the saved position.
If you press any button before reaching the saved position, the desk
stops and the saved position will not be reached.
The display reads the actual desk-height.

5. Technical Data

Supply voltage
Current consumption (average)
Life cycle (switching cycles)
Ambient temperature
Cable length
Dimensions (l, w, h)
Weight
Note: The foil of the handswitch might perish or might grow pale due to
intensive UV radiation. Therefore avoid direct solar radiation!

6. Appendix

6.1

Possible Errors and Solutions

This chapter offers detailed information on possible troubles and solutions:
Display does not work (buttons work)
Possible Cause
Cable is defect
Display is defect
Microcontroller is defect
Handswitch is defect
5VDC ± 10%
75 mA
10. 000
0 – 50° C
2000 mm ± 20mm
126mm x 70 mm x 25mm
Without mounting plate
0,3 kg (incl. Cable)
Solution
Contact our customer service
Contact our customer service / change the
handswitch
Contact our customer service / change the
handswitch
Contact our customer service / change the
handswitch
