LOGICDATA COSMO SYDNEY Original Instructions Manual page 13

STEP 1: PREPARING THE OUTER FRAME
DO NOT REMOVE PROTECTIVE MATERIAL
DO NOT REMOVE STRAPPING TAPE
L L
W A
USE LABELS ON SIDE RAILS
STEP 2: ATTACHING THE LEGS
D
A
C
Lay the Crossbars (D) and Side Rails (A, B) on
the ground, as shown in the picture.
IMPORTANT:
▪
Ensure the Crossbars are parallel and
roughly 5 feet (150 cm) apart.
▪
Use the labels on the Side Rails to ensure
they are oriented correctly.
▪
Use the Crossbars to determine the position
of the Side Rails. The Side Rails should be
the width of the Crossbar apart.
A B
COSMO SYDNEY ADJUSTABLE BED FRAME – ORIGINAL INSTRUCTIONS // 13
INSIDE OF FRAME
B
D
1. Position the first Leg (C) below
the Side Rail (A/B) as shown in
the picture.
2. Turn the Leg to screw it into
the Side Rail. It should be hand
tight.
3. Repeat Steps 1 and 2 to Screw
in the other 3 Legs.
