<For 45-degree specifications>
Product size
677mm
<For tabletop specifications>
Product size
677mm
Supplement
The installation size (area) when installing on a tabletop should be larger size than the product size.
There is no specific recommended value for the height when installing on a tabletop.
Product size and installation size
Product size
1230mm
Installation size
840mm or more
Product size
1360mm
V
Product size
326mm
Installation size
470mm or more
Product size
326mm
