2.1

Media Preparation

Usable media

The following media is available for ASF1-30.
• Sheet media for laser printers (thickness 0.15 to 0.23 mm)
Supplement
The maximum number of media that can be loaded is 150 sheets, or the maximum stacking height is up to 30 mm.
The following media sizes are available for the ASF1-30:
• A3 Plus (329 x 483 mm)
• A3
• A4
• Letter
Supplement
Media sizes other than those listed above can also be loaded, but the positions of the media guides and push rollers
are not covered by the warranty.
CAUTION
•
When using ASF1-30, the cutting mat cannot be used.
•
If the media is charged with static electricity, the media feeding noise may become louder or the media may not be
feed properly. Please fan the media well before loading it.
Media that easily becomes charged during the printing process can cause media feeding problems.
•
If the edges of the media are not neatly aligned, the registration marks may not be scanned.
Make sure to neatly align the edges of the media before loading it.
•
If you are using curled media, roll it in the opposite direction to flatten it before loading it.
•
Depending on the type of printer or media, curling may occur when printing.
In this case, please print by manually feeding one sheet at a time.
•
Always load media vertically.
Do not mix media of different materials or sizes.
•
The maximum number of media that can be loaded is 150 sheets, or the maximum stacking height is up to 30 mm.
•
Media repeatedly absorbs and releases moisture depending on the humidity. Moisture absorption can cause
the media to curl and become dusty, so when not in use, return it to the package and store it away from high
temperatures, high humidity and direct sunlight.
•
Do not use media that has been surface treated for inkjet printing on both sides.
Dirt may accumulate on the rollers, causing problems with media feed.
Clean the rollers if they become dirty.
