A.1

Specifications

Compatible media size
Maximum number of media that can be
loaded
Compatible media
Operating environment
Curl Tolerance
External dimensions (approx.)
(when used at 45-degree) (W × D × H)
External dimensions (approx.)
(when used on a tabletop) (W × D × H)
ASF1-30 Body Weight (approx.)
Weight of paper eject section (approx.)
* Do not apply a load exceeding 4.5 kg to the paper output tray.
Letter/A4/A3/A3 Plus (Vertical only)
100 sheets (thick paper) to 150 sheets (thin paper)
* Even if the maximum number of media sets is within the range, the total weight
must be 4.5 kg or less.
Tack paper (for laser printer)
Thickness 0.15 to 0.23 mm (157 to 181 g/m
* Basis weight is for reference only
* Static electricity generating media and copy paper, etc. are not available.
15°C to 30°C 70% (no condensation)
5 mm or less
677 × 1230 × 633 mm
Table height 470 mm or more
677 × 1360 × 326 mm
7.2 kg
6.6 kg
