SOMFY CONTROL BOX 3S io Installation Instructions Manual
Hide thumbs
Also See for CONTROL BOX 3S io:
- Installation instructions manual (68 pages) ,
- User manual (60 pages) ,
- Installtion instructions (9 pages)
Related Manuals for SOMFY CONTROL BOX 3S io
Summary of Contents for SOMFY CONTROL BOX 3S io
- Page 1 CONTROL BOX 3S io Manuel d’installation Installatiehandleiding Installation instructions D811864_02_20-01-2015 027908 4 0 3 8 0 3...
-
Page 2: Table Of Contents
TECHNICAL DATA ___________________________________________________________ 22 ® io-homecontrol provides advanced and secure radio technology that is easy to install. io-homecontrol ® labelled products communicate with each other, improving comfort, security and energy savings. www.io-homecontrol.com Copyright © 2011 Somfy SAS. All rights reserved... -
Page 3: Safety Instructions
This product is a control cabinet for swing gates, for residential use. To ensure compliance with the standard EN 60335- 2-103, this product must be installed with a Somfy motor. The assembly is together designated as a “motorisation”. The main purpose of these instructions is to satisfy the requirements of the aforementioned standard and to ensure the safety of equipment and persons. -
Page 4: Safety Instructions Relating To Installation
(CONTROL BOX 3S AXOVIA io/CONTROL BOX 3S IXENGO io). Assistance Do not hesitate to contact us; our specialists are on hand to answer all your questions. Internet: www.somfy.com Copyright © 2015 Somfy SAS. All rights reserved... -
Page 5: Product Description
Control Box 3S io PRODUCT DESCRIPTION Area of application The CONTROL BOX 3S is designed to control one or two Somfy 24V motors for opening and closing gates. Composition of the kit Description Programming interface Plug-in terminals Keygo io remote controls... -
Page 6: Installation
Connect terminals 1 and 2 of the control box to the 230V mains power supply. Note: neutral wires in case of detachment. - If class 1 area lighting is to be connected, earth the control box (terminal 3 or 4). Copyright © 2015 Somfy SAS. All rights reserved... -
Page 7: Quick Commissioning
The gate performs two complete Opening and Closing cycles. If auto-programming is correct, the display indicates "C1". If auto-programming has not completed correctly, the display indicates "H0". then then Auto-programming correct Auto-programming incorrect Copyright © 2015 Somfy SAS. All rights reserved... -
Page 8: Operating Test
Compliant* 2 m to 4 m 100 kg to 400 kg * for normal installation measurements; in case of doubt, Somfy recommends measuring the impact force once auto-programming has been successfully performed. OPERATING TEST Using Keygo io remote controls Default sequential operating mode (P01=0) -
Page 9: Connecting Additional Devices
Safety input 2 - programmable Contact Contact Safety test output Contact COMPLETE/OPENING control input COMPLETE/OPENING cycle programmable Shared Contact PEDESTRIAN/CLOSING control input PEDESTRIAN/CLOSING cycle programmable Conductor Aerial Do not change the position of the aerial. Braid Copyright © 2015 Somfy SAS. All rights reserved... -
Page 10: Description Of The Various Additional Devices
Lock (Fig. 7) Not operational using backup battery power. Battery (Fig. 8) Life: 3 cycles/24 hrs Area lighting (Fig. 9) For class I lighting, connect the earth wire to terminal 3 or 4. Note: Copyright © 2015 Somfy SAS. All rights reserved... - Page 11 Control Box 3S io 24V dc 24V Cell sec./Cell 24V dc 24V Cell sec./Cell 3 5 RX1 3 RX2 24V Cell sec./Cell 24V dc 24V dc 24V Cell sec./Cell 24V dc 24V Cell sec./Cell Copyright © 2015 Somfy SAS. All rights reserved...
- Page 12 Ant. sec./Cell 24V dc 24V Cell Lock Sec. Prog Test Sec. 24V Cell sec./Cell Lock Sec. Prog Test 24V dc Sec. 500 W max. Lock Sec. Prog T Lamp Batt..Copyright © 2015 Somfy SAS. All rights reserved...
-
Page 13: Advanced Parameter Setting
The automatic closing time delay can be programmed in parameter "P04" (short time delay) or parameter "P05" (long time delay). P04 Short automatic closing time delay in pedestrian cycle 2: 20 s Copyright © 2015 Somfy SAS. All rights reserved... - Page 14 A of the standard EN12 453 or install a safety edge. zone 5: longest slowdown zone Default value: 1 P22 Opening slowdown 0: shortest slowdown zone zone 5: longest slowdown zone Default value: 1 Copyright © 2015 Somfy SAS. All rights reserved...
- Page 15 4: fastest speed Default value: 2 with appendix A of the standard EN12 453 or install a safety edge. P41 Coupling speed when 1: slowest speed opening 4: fastest speed Default value: 2 Copyright © 2015 Somfy SAS. All rights reserved...
-
Page 16: Memorising The Remote Controls
Memory full (only for monodirectional remote controls) Memorising the Keygo io remote controls Memorising via the programming interface COMPLETE opening control PEDESTRIAN opening control LIGHTING control AUXILIARY OUTPUT control (P15 = 4.5 or 6) Copyright © 2015 Somfy SAS. All rights reserved... -
Page 17: Memorising The Keytis Io Remote Controls
Keytis io, Telis io, Impresario io, Composio io remote controls: press the "KEY" button until the green indicator light comes on (2 s). Other remote control: refer to the instructions. [2]. Remote control memorised Remote control to be memorised Copyright © 2015 Somfy SAS. All rights reserved... - Page 18 [1]. Press the "PROG" button on the memorised remote control until the green indicator light comes on (2 s). [2]. PROG" button on the new remote control. Remote control memorised Remote control to be memorised Copyright © 2015 Somfy SAS. All rights reserved...
-
Page 19: Memorising 3-Button Remote Controls (Telis Io, Telis Composio Io, Etc.)
[2]. Press "PROG" at the rear of the 3-button remote control to memorise the function. - - - The screen displays "Add". Memorising by copying a previously memorised 3-button io remote control Remote control memorised Remote control to be memorised Copyright © 2015 Somfy SAS. All rights reserved... -
Page 20: Clearing The Remote Controls And All Settings
When the programming buttons are locked, a dot appears after the 1st digit. Press the "SET", "+" and "-" buttons. - the "SET - the "+" and "-" buttons must be pressed simultaneously within 2 seconds. To access the programming again, repeat this procedure. Copyright © 2015 Somfy SAS. All rights reserved... -
Page 21: Diagnostics
Pressing a button on the remote control allocates this button to the auxiliary output control. auxiliary output control Pressing "PROG" once more switches to "awaiting remote control memorisation for operation in complete opening mode: F0". Copyright © 2015 Somfy SAS. All rights reserved... -
Page 22: Fault And Breakdown Code Display
Disconnect the backup battery and connect the control box to the mains to supplied by the backup battery For all other error codes or faults, please contact Somfy. Accessing memorised data To access memorised data, select parameter "Ud" then press "OK". -
Page 23: Technical Data
Opening speed Closing speed Coupling speed when closing Lock release - electric door-opener release Holding gate in open/closed position Gate leaf shift Programmable Diagnostics radio channels, log of the last 10 stored faults Copyright © 2015 Somfy SAS. All rights reserved... - Page 24 Somfy BP 152 - 74307 Cluses Cedex France www.somfy.com 5105536B...
