Control Box 3S io
Electrical pre-equipment
The installation of the power supply must comply with the standards in force in the country in which the motorisation is
The electric line must be exclusively reserved for the motorisation and equipped with protection, comprising:
- a 10 A fuse or breaker,
- a differential type device (30 mA).
An all-pole supply cut-off device must be provided.
> Cable feed
the accessories cables.
For overground cables, use a cable grommet that will withstand the weight of vehicles (ref. 2400484).

Safety instructions relating to installation

Do not connect the motorisation to a power supply (mains, battery or solar) before installation is complete.
Modifying one of the elements provided in this kit or using an additional element not recommended in this manual is strictly
prohibited.
Monitor the gate as it moves and keep people away from it until installation is complete.
Do not use adhesive to secure the motorisation.
After installation, ensure that:
- the mechanism is correctly adjusted
- the manual back release device is operating correctly
- the motorisation changes direction when the gate encounters an object 50 mm high positioned halfway up the leaf.
> Safety devices
For operation in automatic mode or remote control, photoelectric cells must be installed.
For operation in automatic mode, or if the gate faces a public road, an orange light type signalling device may be
required to comply with the regulations in the country in which the motorisation is installed.
> Clothing precautions
Take off any jewellery (bracelet, chain, etc.) during installation.
For manoeuvring, drilling and welding operations, wear appropriate protection (special glasses, gloves, ear protection,
etc.).
Regulations
SOMFY declares that this product complies with the essential requirements of applicable European directives. A declaration
of conformity is available at www.somfy.com/ce (CONTROL BOX 3S AXOVIA io/CONTROL BOX 3S IXENGO io).
Assistance
Do not hesitate to contact us; our specialists are on hand to answer all your questions. Internet: www.somfy.com
3
