SOMFY CONTROL BOX 3S io Installation Instructions Manual page 14

Control Box 3S io
Values
Code Description
(bold = default)
P05 Long automatic
closing time delay in
pedestrian cycle 0: 0 s
P07 Cell safety input
1: active
supply switching
4: bus cells
P09 Programmable safety
input 1: active
supply switching
P10 Programmable safety 0: active closing
input - function
P11 Programmable safety 0: stop
input - action
2: stop + complete reversal
P12 Orange warning light 0: no warning
P13 Area lighting output
1: controlled operation
2: automatic + controlled
operation
P14 Area lighting time
delay 6: 60 s
P15 Auxiliary output
1: automatic: gate open indicator light
2: automatic: timed bistable
3: automatic: one-touch
4: controlled: bistable (ON-OFF)
5: controlled: one-touch
6: controlled: timed bistable
P16 Auxiliary output time
delay 6: 60 s
P17 Lock output 0: active 24V one-touch
P18 Lock release 0: inactive
P19 Closing speed 1: slowest speed
at
10: fastest speed
Default value:
- Control Box 3s Axovia io: 5
P20 Opening speed
- Control Box 3s Ixengo io: 6
P21 Closing slowdown 0: shortest slowdown zone
zone at
5: longest slowdown zone
Default value: 1
P22 Opening slowdown 0: shortest slowdown zone
zone at
5: longest slowdown zone
Default value: 1
13
Setting
Comments
completed
Value 0 must be selected if the short automatic closing time delay in pedestrian cycle is
0: the safety input is not taken into account.
months.
the cell power supply output (terminals 21 and 22).
4: bus cells application.
0: the safety input is not taken into account.
1:
the cell power supply output (terminals 21 and 22).
cannot be opened.
0: emergency stop application, compulsory if P10=3
disabled if a safety edge is connected to the programmable safety input
1: recommended for safety edge application
2: recommended for cell application
P12=1.
0: the area lighting output is not taken into account.
1: the area lighting is remotely controlled.
for the duration of the time delay programmed in parameter "P14".
P13=2 is compulsory for operation in automatic mode.
0: the auxiliary output is not taken into account.
on when the gate is open.
the time delay programmed in parameter "P16".
4: operation changes as follows each time the memorised button on the radio control point is
pressed: ON, OFF, ON, OFF...
5: one-touch at contact by pressing the memorised button on the radio control point.
The lock is released at the start of opening.
1: recommended for use with an electric lock.
with appendix A of the standard EN12 453 or install a safety edge.
.
P16".
