Control Box 3S io

MEMORISING THE REMOTE CONTROLS

General information

Remote control types
There are two types of remote control:
io,Telis 1 io, Telis Composio io, Impresario Chronis io
Memorising the remote controls
There are two ways to memorise a remote control:
Memorising via the programming interface.
Memorising by copying a previously memorised remote control.
Memorising a button which has already been memorised will clear this button's function.
Meaning of displayed codes
Code Description
Add Successful memorisation of a monodirectional remote control
- - - Successful memorisation of a bidirectional remote control
dEL
rEF Unsuccessful memorisation of a bidirectional remote control
FuL Memory full (only for monodirectional remote controls)

Memorising the Keygo io remote controls

Memorising via the programming interface
COMPLETE opening control
PEDESTRIAN opening control
C1
2 s
LIGHTING control
C1
2 s
AUXILIARY OUTPUT control (P15 = 4.5 or 6)
C1 F0
2 s
15
C1 F0
2 s
F0 F1
F0
F1
F1
Add
F2
F2 F3
C1
Add C1
Add C1
Add
