Control Box 3S io

CONNECTING ADDITIONAL DEVICES

General wiring diagram

230 V
500 W max.
230 V
... ...
50 Hz
230Vac Lamp Aux
L N
1 2 3 4 5 6 7
1.5 mm² 0.75 mm²
Terminals Terminal indication
1 L
2 N
3
4
5 N
6 L
7 Contact
8 Shared
9 0 V
10 9 V - 24 V
11
12 -
13 End limit
14
15 -
16 End limit
17 24 V - 15 W
18 0 V
19 24 V
20 0 V
21 24 V
22 0 V
23 Shared
24 Contact
25
26 -
27 Shared
28 Contact
29 Contact
30 Contact
31 Shared
32 Contact
33 Conductor
34 Braid
Copyright © 2015 Somfy SAS. All rights reserved
M1 M2
Batt. M1 M2
- +
M M
- -
+ FC + FC
8 9 1 0 1 1 1 2 1 3 1 4 1 5 1 6
1.5 mm² 1.5 mm²
0.75 mm²
Connection
230 V power supply
Earth
230 V lighting output
Auxiliary contact output
Motor 1
Ixengo only
Motor 2
Ixengo only
24 V - 15 W orange light output
24 V accessories power supply
Safety input 1 - Cells
24 V lock or 12 V lock output
Safety input 2 - programmable
Safety test output
COMPLETE/OPENING control input
PEDESTRIAN/CLOSING control input
Aerial
15 W
TX RX
24 Vdc
Flash 24V dc 24V Cell sec./Cell Lock
17 18 1 9 2 0 2 1 2 2 2 3 2 4
2 5 2 6
0.75 mm²
*
Comments
Max. power 500 W
Protected by 5A time-delay fuse
Dry contact for 24V, 2A max, Safety Extra Low Voltage (SELV)
At 9 V, degraded operation
At 24 V, normal operation
1.2 A max for all accessories on all outputs
Permanent if autotest not selected, controlled if autotest selected
BUS compatible (see parameter table)
Programmable (parameter P17)
COMPLETE/OPENING cycle programmable
PEDESTRIAN/CLOSING cycle programmable
Do not change the position of the aerial.
Sec. Prog Test Ant.
Sec.
33 34
2 7 2 8 2 9 3 0 3 1 3 2
