Chez Somfy, la recherche de la qualité est un processus d’amélioration permanent. Ne pas laisser les enfants jouer avec les dispositifs de commandes fixes. C’est sur la fiabilité de ses produits que s’est construite la renommée de Somfy, Mettre les dispositifs de télécommande hors de portée des enfants.
Ce produit est destiné aux portails pour des maisons individuelles (décrit ci-contre). Dimensions et poids maxi Dégagement minimal, des vantaux portail ouvert (en mm) Caractéristiques techniques Type SGS 501 / SGS 601 Tension d’alimentation 230 V~ / Solaire Type de moteur 24 Vdc Puissance du moteur 40 W Puissance maxi consommée...
Il reste horizontal pendant toute sa course. Il s’ouvre vers l’intérieur de votre propriété. Types de portails motorisables (Sous réserve du respect des cotes d’implantation pages 6 et 18). SGS 501/601 : tous types de portails (fer, aluminium, PVC). Renforts * pour scellement chimique avec vis M10.
Page 7
Pré-équipement électrique Les cellules En option sur SGS 501, fournies avec SGS 601. Pour motoriser votre portail : Les cellules sont obligatoires pour un fonctionnement en mode automatique et pour une ouverture • Aménagez une arrivée électrique 230 V à l’un des piliers et au plus près de sur zone publique.
• le sens de montage (E ou e) de la patte de Maintenez la patte à l’horizontale. fixation vérin. A l’aide d’un forêt à béton de petit diamètre (4 ou 5 mm), pré-percez 2 SGS 501 / 601 : trous destinés à recevoir les scellements chimiques, chaque pilier, (* Pour d’autres cotes, voir page 18).
Montage de la patte de fixation vantail (6). o Accrochage / décrochage du vérin. o Pose des scellements. SOMFY préconise de fixer la patte (1) avec un scellement chimique pour sa fiabilité. Positionnez la patte de fixation vérin (1) Retirez la patte. Placez les 2 scellements sur le pilier et vérifiez que les orifices...
Page 10
Pose des vérins Pose des vérins o montage de la patte de fixation vantail (6). Ne faites jamais fonctionner votre vérin avant d’avoir terminé sa fixation Marquez les perçages des points de fixation du bord de la pièce sur le renfort du vantail au travers de l’équerre vantail.
raccordements électriques raccordements électriques n Les étapes : o raccordement des deux vérins. o Position du boîtier électrique sur le pilier. La liaison entre les vérins et le boîtier électrique doit être effectuée avant le raccordement du boîtier électrique au secteur. o Fixation du boîtier électrique sur le pilier.
PROG AUTO raccordements électriques Paramétrage ON/OFF n Les étapes : o Connection de l’antenne. o Présentation des symboles. Pour un fonctionnement optimal, il est o Mémorisation des télécommandes. recommandé de sortir le fil d’antenne du boîtier au travers d’un passe-fils. o Réglage des butées d’ouverture.
Page 13
Paramétrage Paramétrage Suppression des télécommandes mémorisation des télécommandes en ouverture totale seule : Choisissez la touche de la télécommande que vous souhaitez utiliser pour commander votre • Appuyez 7 secondes sur le bouton de portail. remise à zéro (reset). Posez la télécommande sur la cible gravée >...
Page 14
Durant cette phase le bouton de la télécommande programmée fonctionne en mode séquentiel L’électronique Somfy mémorise automatiquement : ( cycle d’appui = ouverture/stop/fermeture/stop/ouverture …), il est donc possible de régler la • La force des vérins nécessaire à la commande des portails, en fonctionnement normal.
Page 15
Paramétrage Paramétrage • Lancez une ouverture (à distance Vérification du bon paramétrage normale) avec la télécommande. Effectuez un appui long sur la télécommande. > Le portail s’ouvre à vitesse nominale. Effectuez un nouvel appui pour que les 2 vantaux s’arrêtent en milieu de course. Une fois le portail complètement ouvert : Coupez l’alimentation du secteur 5 secondes minimum.
Utilisation Utilisation n Fonctionnement en mode séquentiel n Fonctionnement de l’éclairage Fonctionnement de l’ouverture totale L’éclairage de zone s’allume à chaque mise en route de la motorisation. Il s’éteint automatiquement • Effectuez un appui long sur la télécommande. après la fin du mouvement au bout de 2 minutes en cas d’alimentation électrique ou au bout de >...
19. Pour tout autre problème ou demande de renseignement sur votre SGS, vous pouvez appeler nos conseillers de Somfy Grand Public 6 jours / 7 : Pour un meilleur fonctionnement des cellules, il est nécessaire de repositionner leur couvercle.
Page 18
accessoires - accessoires - Descriptif et branchements Descriptif et branchements n Batterie de secours 2400720 n Contact à clé 2400597 accessoire incompatible avec une alimentation solaire. batterie secours assure fonctionnement du portail en vitesse lente en cas de défaillance électrique. Elle s’intègre et se raccorde directement dans le boîtier électronique du moteur.
Page 19
accessoires - accessoires - Descriptif et branchements Descriptif et branchements 2400581 n interrupteur mural radio 2400594 n Clavier à code filaire accessoire incompatible avec une alimentation solaire. n Clavier à code radio 2400625 – H P2 M P1 T3 C3 R3 T2 C2 R2 T1 C1 R1 V STOP...
- Complément au relevé des cotes Descriptif et branchements (p.6) pour déterminer la position des vérins sur les piliers. SGS 501 / 601 : angle max. Sens de Sens de montage (mm) (°) (mm) montage pilier droit de 0 à 20 de -30 à...
en cas d’alimentation solaire n accessoires : Cellules Schéma de câblage pour un jeu de cellules 1 2 3 5 Le paramétrage, la programmation et l’utilisation du moteur restent identiques à l’alimentation 230V. o raccordement à l’alimentation solaire Panneau Feu d’éclairage de zone solaire PROG Passez le câble dans le presse- AUTO étoupe du boîtier électrique du ON/OFF...
Page 23
3. Electrical connections ........9 PROG AUTO ON/OFF 4. Parameter setting ........... 10 operation ............. 14 SGS 501 troubleshooting guide ........15 Accessories ............15 Additional information to summary of dimensions 18 SGS 601 Use with solar power ......... 19...
Ensure that any danger zones (crushing, cutting, trapping) between the driven part and ask for advice at your DIY store or contact a Somfy advisor directly for help and the surrounding fixed parts created by the opening of the driven part are avoided.
IP 55 for electronics IP 44 for motors Integrated radio receiver Remote controls: • Radio frequency 433.42 MHz D = 210 (SGS 501/601) • Range in field of use ≈ 30 m • Storage quantity Possible connections: • Output for orange light Flashing, 24 V, 10 W •...
It remains horizontal throughout its travel. It opens inwards towards your property. types of gates which can be motorised (Provided that the installation dimensions on pages 6 and 18 are respected). SGS 501/601: all types of gate (iron, aluminium, PVC). Reinforcements Reinforcements fitted...
Page 27
Preliminary operations nElectrical pre-equipment Cells Optional on the SGS 501, supplied with the SGS 601. To motorise your gate: The cells are essential for operation in automatic mode and for opening in public areas. • Fit a 230 V electrical input to one of the pillars and as close as possible to the SGS motor.
Hold the bracket horizontal. der mounting bracket. Using a small diameter (4 or 5 mm) concrete drill bit, pre-drill 2 holes for the SGS 501/601: chemical anchorages, on each pillar, at the positions marked. (* For other dimensions, see page 18).
Fitting the gate leaf mounting bracket (6). o Coupling/uncoupling the cylinder. o Fitting the anchorages. SOMFY recommends that the bracket (1) be fixed using a chemical anchorage, owing to its reliability. Position the cylinder mounting bracket Remove the bracket. Place the 2...
Page 30
Fitting the cylinders Fitting the cylinders o Fitting the gate leaf mounting bracket (6). never operate cylinder before correctly mounting gate Mark the drill holes for the mounting points of the edge of the part on the gate leaf reinforcement through the gate leaf bracket.
Electrical connections Electrical connections n Steps: o Connecting the two cylinders. o Positioning the electric unit on the pillar. The cylinders and the electric unit must be connected before the electric unit is connected to the power supply. o Mounting the electric unit on the pillar. o Connecting the two cylinders.
PROG AUTO Electrical connections Parameter setting ON/OFF n Steps: o Connecting the aerial. o Introduction to symbols For optimal operation, it is recommended to o Storing the remote controls feed the unit's aerial wire via a grommet. o Setting the opening end stops. o Programming the gate leaves' travel.
Page 33
Parameter setting Parameter setting Clearing the remote controls Programming the remote controls for full opening only: Select the remote control button which you want to use to control your gate. • Press and hold the reset button for 7 Fit the remote control on the target engraved seconds.
Page 34
Programming the gate leaves' travel. During this phase, the remote control button programmed operates in sequential mode (cycle Somfy electronics automatically stores: when pressed = opening/stop/closing/stop/opening etc.), it is therefore possible to set the • The cylinder force required to control the gates, in normal operation.
Page 35
Parameter setting Parameter setting • Begin opening (normal remote ope- Checking the parameters are correct ning) using the remote control. Press and hold the button on the remote control. > The gate opens at normal speed.. Press the button again so that the 2 gate leaves stop mid-travel. Once the gate is fully open: Switch off the power supply for at least 5 seconds.
operation operation n operation in sequential mode n Area lighting operation Full opening operation Area lighting comes on each time the motor is switched on. After the end of movement, it goes off • Press and hold the button on the remote automatically after 2 minutes when supplied by electricity or after 30 seconds when supplied by solar control.
For solar power, see page 19. If you have any other problems or queries concerning your SGS, please contact our advisors by calling the Somfy UK Hotline : 0113 391 30 30 For optimum cell operation, it is necessary to reposition the cell cover.
Page 38
Accessories - Accessories - Description and connections Description and connections n Backup battery 2400720 n Key lock 2400597 Accessory not compatible with solar power. The backup battery ensures the operation of the gate at low speed in the event of an electrical power failure. It is integrated and connected directly to the motor's electronic unit.
Page 39
Accessories - Accessories - Description and connections Description and connections 2400581 n Wall-mounted radio switch 2400594 n Wired code keypad Accessory not compatible with solar power. n Radio code keypad 2400625 – H P2 M P1 T3 C3 R3 T2 C2 R2 T1 C1 R1 V STOP 2400549...
Additional information to summary of Accessories - Description and connections dimensions (p.6) to determine the position of the cylinders on the pillars. SGS 501/601: Max. angle Direction Direction of fitting, (mm) (°) (mm) of fitting right-hand pillar 0 to 20 -30 to 0 0 to 20 90°...
Use with solar power n Accessories: Cells Wiring diagram for a set of cells 1 2 3 5 the parameter setting, programming and use of the motor are the same as with 230V power supply. o Connection to the solar power supply Area lighting Solar panel...
Page 44
LS19 7BN Tel. 0113 391 3030 Fax. 0113 391 3010 Somfy SAS dans un souci constant d’évolution et d’amélioration peut modifier le produit sans préavis. Photos non contractuelles. Utilisable en UE, CH Somfy SAS in a constant concern of evolution and improvement may modify the product without Usable in EU,CH prior notice.
