Lockly SECURE PRO LATCH EDITION Installation Manual page 15

Step 6
continued
When you are installing the door sensors, make
sure the arrow of the wired sensor
next to the arrow of the sensor magnet
close as possible.
IMPORTANT: Do not install the sensor
close to the strike plate
PREPARING DOOR SENSORS FOR INSTALLATION
AA
is placed
AB
H
.
AA
AA
AB
as
LEFT
H
AB
H
If needed add Foam Pads to level
AA & AB as much as possible.
14
OR
RIGHT
2-3/8"
(60mm)
< 3/4"
(< 20mm)
EVA
2-3/4"
(70mm)
