- Page 1 SECURE PRO INSTALLATION GUIDE LATCH EDITION...
- Page 2 Go to Lockly.com/installation to watch a video version of this installation guide. Download the BILT app in the App Store or on Google Play for step-by-step interactive 3-D walk-through installation instructions.
- Page 3 Welcome! This guide will walk you through step-by-step how to install and get your Lockly Secure Pro up and running. Installation generally takes less than 30 minutes. If you have any questions please reference our online support at: Lockly.com/support or call (669) 500-8835 for help.
- Page 4 Preparation To complete the installation you will need: Phillips Screwdriver Flathead Screwdriver Tape measure or ruler Pliers Screwdriver with drill bits （Optional） Drilling is not required to install the lock, and is optional. However if you are installing your lock on a brand new door, a drill is required if there are no holes prepared for lock installation.
-
Page 5: Important Notice
Preparation Remove existing door hardware, latch or deadbolts before installing the new lock. Use provided template to bore new holes if needed. 1-3/8" ~ 2" (35mm ~ 50mm) Measure and confirm your door is between 1-3/8" ~ 2" ( 35mm - 50mm). Measure and confirm the hole in the door is 2-1/8"... - Page 6 Step 1 INSTALLING THE LOCKSET Measure the distance between center of front door 2-3/8" hole to the edge of your door. Push the shaft (a) to (60mm) adjust the lockset to 2-3/8"(60mm) or 2-3/4"(70mm). 2-3/4" (70mm) Facing the door exterior, install the lockset according to the opening direction of your door. Out-swing Door In-swing Door Secure lockset with provided...
- Page 7 Step 2 CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS Determine right swing or left swing door While facing the door from the inside, if hinges are on the right side you have the right swinging door. If hinges on the left side you have a left swinging door. The lock ships set for right swing doors.
- Page 8 Step 2 CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS continued Check that your handle works Confirm that your installation was smoothly by giving it a turn up complete by checking if the pins and down. are flush against the handle, and has popped out.
- Page 9 Step 2 CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS continued Changing the Interior Handle Orientation Remove the screw by turning counter Securely screw clockwise as shown clockwise and rotate the handle 180° to complete your handle orientation change. in the direction of the arrow as shown. Make sure the screw hole is aligned with the marker as illustrated.
- Page 10 Step 3 PREPARING LOCK FOR INSTALLATION If you drilled a hole in Preparation, use Slotted Barrel Extension and securely tighten with a flat head screwdriver by turning it clockwise onto the lock. If you did not drill a hole in Preparation, you can leave this pole removed.
- Page 11 Step 4 INSTALLING THE LOCK (EXTERIOR) Exterior Install the exterior lock as shown to the left by aligning the lock straight and passing the cable and attached rods through the lockset. Align the lock straight and press hard (if you use the Adhesive tape in step 3.4) to secure the top of the lock.
- Page 12 Step 5 INSTALLING THE LOCK (INTERIOR) Interior Insert Positioning Rods into the holes to the left and right of the Spindle The holes are located at the 3 o’clock and 9 o’clock positions. Interior Mounting Plate will go against the interior side of your door. Remove the paper layer off of the Adhesive Tape align the positioning rods on the bottom of the plate to the corresponding left and...
- Page 13 Step 5 INSTALLING THE LOCK (INTERIOR) continued Secure with Pull the cable from the lock exterior through the rectangular hole under- neath the positioning rods and spindle. Secure the hole above the spindle with screws Remove the position rods *Secure top with replace them with screws Tighten clockwise until the mounting plate...
- Page 14 It also sends push notifications to your phone whenever your door opens and enables voice control with Amazon Alexa or Google assistant. Lockly Secure Pro comes with a pre-wired door sensors consisting of two parts: Part (AB) - Sensor Magnet...
- Page 15 Step 6 PREPARING DOOR SENSORS FOR INSTALLATION continued When you are installing the door sensors, make sure the arrow of the wired sensor is placed next to the arrow of the sensor magnet close as possible. IMPORTANT: Do not install the sensor LEFT close to the strike plate RIGHT...
- Page 16 Step 6 PREPARING DOOR SENSORS FOR INSTALLATION continued The interior assembly comes with the For left swing doors, re-route the door pre-installed wired door sensor setup for sensor wire through the side channel. a right swing doors with 2 ¾" (70mm) Trim excess part (e) for doors with 2 ⅜"...
- Page 17 Step 7 INSTALLING THE LOCK INTERIOR (N) Plug the cable that is coming Align the square rod to the lock interior and through the door into the lock attach the Interior lock to the Interior mounting interior. plate. While you are doing so, gently push some of the excess cable through the rectangular hole into the door.
- Page 18 Step 7 INSTALLING THE LOCK INTERIOR (N) continued Once the lock interior is flush against Insert 4 AA batteries into the lock by aligning the positive and negative orientation the mounting plate, secure the lock markings on the batteries to the battery chamber. to the plate by screwing clockwise using provided screws Secure the battery cover by sliding the cover...
- Page 19 Step 8 INSTALLING THE DOOR STRIKE Close your door to see if your lock closes securely with your existing door strike. If the lock closes securely, you may keep the existing door strike without removing the old hardware. However, it’s recommended that you use our door strike.
- Page 20 NOTE: The arrows must be aligned or as closed as possible (less than 3/4"). If needed, adjust the position of the sensor magnet using provided foam pads to ensure the Lockly logo blinks red when door opens or closes.
- Page 21 Step 10 DOWNLOAD LOCKLY APP You have completed the Lockly physical lock installation. To enable live monitoring and voice control with Google Assistant or Amazon Alexa, you will need to setup the included Secure Link Wi-Fi hub and pair it with the Lockly Secure Pro smart lock door sensors.
- Page 22 Step 11 SETTING UP THE SECURE LINK WI-FI HUB To set up your Lockly Secure Pro, choose an appropriate location for the Secure Link Wi-fi Hub for optimum performance (see below). For optimum connectivity, it is recommended that the hub be no further away from the lock than 30 feet (9 meters).
- Page 23 Once you have confirmed that your Secure Link Wi-Fi Hub is ready to connect to your lock, Make sure you are standing between the Wi-Fi open the Lockly App from your smartphone. hub and Lockly smart lock, then Add New Device and follow the on screen instructions.
- Page 24 KEEP THIS CARD! ACTIVATION CARD LOCK SERIAL PGDxxxxxxxxxx ACTIVATION CODE xxxxxxxx SCAN & SAVE LOCKLY.COM | HOTLINE: +1(669) 500-8835 | EMAIL: HELP@LOCKLY.COM If you can't scan LOCK SERIAL, Input Activation Code Scanning LOCK SERIAL Then enter manually ●●●●● AT&T 9:43 AM 100% ●●●●●...
- Page 25 Step 12 CONNECTING YOUR LOCKLY SECURE PRO continued Plug in your Secure Link Password setting OK Confirm lock password and Click "YES" Set the Admin Code ●●●●● AT&T 9:45 AM 100% ●●●●● AT&T 9:46 AM 100% ●●●●● AT&T 9:45 AM...
-
Page 26: Voice Control
Amazon Alexa Skill or Lockly Action on Google. TIP: In Google Home or Amazon Alexa app, add Lockly skill for Alexa or Lockly Action on Google, then follow on screen instructions. See full list of commands, help videos, or troubleshooting your Lockly at https://Lockly.com/help... - Page 27 FCC Warning： This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 28 (LK) KEEP THIS CARD! Locking Pin Wi-Fi Hub ACTIVATION CARD Latch Keys LOCK SERIAL Activation Card PGDxxxxxxxxxx KA4 x 20MM Screw Strike Plate ACTIVATION CODE xxxxxxxx SCAN & SAVE Power Adaptor LOCKLY.COM | HOTLINE: +1(669) 500-8835 | EMAIL: HELP@LOCKLY.COM...
- Page 29 Connect with us @meetlockly | #lockly Reference installation parts overview foldout.
- Page 30 Bluetooth SIG, Inc. , and any ® use of such marks by Lockly is under license. Other trademarks and trade names are those of their respective owners. Google, Android, Google Play and Google Home are trademarks of Google LLC. , Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc., or its affiliates.
