- Page 1 SECURE INSTALLATION GUIDE LATCH EDITION...
- Page 2 Go to Lockly.com/installation to watch a video version of this installation guide. Download the BILT app from the App Store or on Google Play for step-by-step interactive 3-D walk-through installation instructions.
- Page 3 Welcome! This guide will walk you through step-by-step how to install and get your Lockly Secure up and running. Installation generally takes less than 30 minutes. If you have any questions please reference our online support at: Lockly.com/support or call (669) 500-8835 for help.
- Page 4 Preparation To complete the installation you will need: Flathead Screwdriver Tape measure or ruler Phillips Screwdriver Pliers Screwdriver with drill bits （Optional） Drilling is not required to install the lock, and is optional. However if you are installing your lock on a brand new door, a drill is required if there are no holes prepared for lock installation.
-
Page 5: Important Notice
Preparation Remove existing door hardware, latch or deadbolts before installing the new lock. Use provided template to bore new holes if needed. 1-3/8" ~ 2" (35mm ~ 50mm) Measure and confirm your door is 1/2" between 1-3/8" ~ 2" ( 35mm - 50mm). 12mm Measure and confirm the hole in the door is 2-1/8"... - Page 6 Step 1 INSTALLING THE LOCKSET Measure the distance between center of front door 2-3/8" hole to the edge of your door. Push the shaft (a) to (60mm) adjust the lockset to 2-3/8"(60mm) or 2-3/4"(70mm). 2-3/4" (70mm) Facing the door exterior, install the lockset according to the in-swing or out-swing opening direction of your door.
- Page 7 Step 2 CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS The lock ships with handle default for right in-swing or left out-swing door. Check the diagram below if you are unsure of you door orientation. RIGHT IN-SWING DOOR INTERIOR LEFT IN-SWING DOOR Hinge Side LEFT OUT-SWING DOOR...
- Page 8 Step 2 CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS continued Rotate the handle 180° to the other side of the Confirm that your installation was complete lock. by checking if the pins are flush against the handle, and has popped out. Adjust Using your fingers, press the two pins located on the handle accordingly to make sure the the left and right side of the the lock to insert...
- Page 9 Step 2 CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS continued Changing the Interior Handle Orientation Securely screw clockwise as shown Remove the screw by turning counter to complete your handle orientation clockwise and rotate the handle 180° change. in the direction of the arrow as shown. Make sure the screw hole is aligned with the marker as illustrated.
- Page 10 Step 3 PREPARING LOCK FOR INSTALLATION If you drilled a hole in Preparation, use Slotted Barrel Extension and securely tighten with a flat head screwdriver by turning it clockwise onto the lock. If you did not drill a hole in Preparation, you can leave this pole removed.
- Page 11 Step 4 INSTALLING THE LOCK (EXTERIOR) Exterior Install the exterior lock as shown to the left by aligning the lock straight and passing the cable and attached rods through the lockset. Align the lock straight and press hard (if you use the Adhesive tape in step 3.4) to secure the top of the lock.
- Page 12 Step 5 INSTALLING THE LOCK (INTERIOR) Interior Insert Positioning Rods into the holes to the left and right of the Spindle The holes are located at the 3 o’clock and 9 o’clock positions. Interior Mounting Plate will go against the interior side of your door. Remove the paper layer off of the Adhesive Tape align the positioning rods on the bottom of the plate to the corresponding left and...
- Page 13 Step 5 INSTALLING THE LOCK (INTERIOR) continued Secure with Pull the cable from the lock exterior through the rectangular hole underneath the positioning rods and spindle. Secure the hole above the spindle with screws Remove the position rods replace them with screws *Secure top with Tighten clockwise until the mounting plate is secure.
- Page 14 Step 5 INSTALLING THE LOCK (INTERIOR) continued Plug cable that is coming through the door into the lock interior . Match red side of the plug with red on socket - insert tightly. NOTE: If you need to disconnect the cable, make sure to press the snap tab to release the plug before carefully pulling it out.
- Page 15 Step 5 INSTALLING THE LOCK (INTERIOR) continued Once the lock interior is flush against the mounting plate, secure the lock to the plate by screwing clockwise using provided screws Insert 4 AA batteries into the lock by aligning the positive and negative orientation markings on the batteries to the battery chamber.
- Page 16 Step 6 INSTALLING THE DOOR STRIKE Close your door to see if your lock closes securely with your existing door strike. If the lock closes securely, you may keep the existing door strike without removing the old hardware. However, it’s recommended that you use our door strike.
- Page 17 Step 7 DOWNLOAD THE LOCKLY APP Congratulations! You have completed the Lockly Secure physical lock installation. To complete your setup, download the Lockly app from the App Store or on Google Play and follow on-screen instructions. Scan or visit Lockly.com/app...
- Page 18 Add more Smart to your Home Secure Link Wi-Fi Hub Add the optional Lockly Secure Link Wi-Fi Hub, together with the free Lockly app, it's easier than ever to securely control and manage your door from anywhere, anytime. Real-time, monitoring, & status...
- Page 19 FCC Warning： This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 20 Positioning Rod For installing mounting plate (LK) KEEP THIS CARD! Latch Locking Pin Keys ACTIVATION CARD KA4 x 20MM Screw Strike Plate LOCK SERIAL Activation Card PGDxxxxxxxxxx ACTIVATION CODE xxxxxxxx SCAN & SAVE LOCKLY.COM | HOTLINE: +1(669) 500-8835 | EMAIL: HELP@LOCKLY.COM...
-
Page 21: Connect With Us
Connect with us @meetlockly | #lockly... - Page 22 Reference installation parts overview foldout.
- Page 23 Bluetooth SIG, Inc. , and any ® use of such marks by Lockly is under license. Other trademarks and trade names are those of their respective owners. Google, Android, Google Play and Google Home are trademarks of Google LLC. , Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc., or its affiliates.
