17 Differences between RTL8762A & RTL8762C

There are changes in 40MHz Crystal request. RTL8762C can only use crystal with CL=<9pF.

PAD has anti-backflow mechanism. All PADs support wakeup function without limitation.

PAD can support 1 set of AON debounce.

PAD will not leak current when the voltage is at intermediate level.

P0_3 polarity is opposite to RTL8762A. The flash content will not be cleared after P0_3
bypass mode is triggered.

There are changes in IO. For more details, refer to the Datasheet.

RTL8762CJ, RTL8762CK require external Flash.

There are 2 sets of ADCAUX ADC and audio ADC. Method of AUX ADC usage is different.

There are changes in DC/DC buck circuit materials.

Mass production needs to program eFuse.
