- Page 1 Ameba-Z DEV01 User Manual This document defines pin out of Ameba-Z DEV01 demo board.
-
Page 2: Table Of Contents
Ameba-Z DEV01 1V0 Table of Contents HARDWARE BLOCK DIAGRAM ........................5 SYSTEM REQUIREMENTS ..........................5 PIN MUX ALTERNATE FUNCTIONS ......................... 6 3.1..............................6 IN MUX TABLE 3.2............................. 8 IN OUT REFERENCE FEATURES ................................9 HARDWARE CONFIGURATION ........................11 5.1. - Page 3 Ameba-Z DEV01 1V0 List of Tables Table 1 Ameba-Z pinmux table ..........................6 Table 2 Ameba-Z Features............................9 Table 3 Ameba-Z LOGUART EFUSE ........................11 3/19...
- Page 4 Ameba-Z DEV01 1V0 List of Figures Figure 1 Ameba-Z DEV Diagram ..........................5 Figure 2 Ameba-Z SWD & LOGUART ........................ 11 Figure 3 Ameba-Z CMSIS-DAP ..........................12 Figure 4 Ameba-Z CMSIS-DAP Firmware update....................13 Figure 5 Ameba-Z Schematics DC-Power ......................14 Figure 6 Ameba-Z Schematics DAP ........................
-
Page 5: Hardware Block Diagram
Ameba-Z DEV01 1V0 Hardware block diagram IC: RTL8710B Module HDK version: HDK-XXXX DEV HDK version: RTL-AMEBAZ_DEV01_1V0 Figure 1 Ameba-Z DEV Diagram System requirements Windows PC(XP,Vista,7) USB type 5/19... -
Page 6: Pin Mux Alternate Functions
Ameba-Z DEV01 1V0 Pin mux Alternate Functions 3.1. Pin mux table Table 1 Ameba-Z pin mux table QFN68 QFN48 QFN32 PWM/ GPIO UART SPI Master SPI Slave SPI Flash SDIO EXT32K Others 8711BG 8711BN 8710BN TIMER PA_14... - Page 7 Ameba-Z DEV01 1V0 QFN68 QFN48 QFN32 PWM/ GPIO UART SPI Master SPI Slave SPI Flash SDIO EXT32K Others 8711BG 8711BN 8710BN TIMER I2S_SD_T PA_19 UART0_CTS SPI1_CS SPI0_CS I2C0_SDA SD_D3 TI MER5_TRIG ADC1 I2S_SD_R PA_20 SD_CMD ADC3 ...
-
Page 8: Pin Out Reference
Ameba-Z DEV01 1V0 3.2. Pin out reference 8/19... -
Page 9: Features
Ameba-Z DEV01 1V0 Features Table 2 Ameba-Z Features Feature list QFN68 QFN48 QFN32 RTL8711BG RTL8711BN RTL8710BN Core type ARM CM4F Integrated core Core clock maximum freq. 125MHz Memory Internal ROM 512KB Internal SRAM 256KB External FLASH 128MB Float process unit... - Page 10 Ameba-Z DEV01 1V0 Feature list QFN68 QFN48 QFN32 RTL8711BG RTL8711BN RTL8710BN Normal GDMA 2*6 channels GPIO IN/OUT/INT D/H/M/S OUTPUT Timer Basic timer use 32K Advanced timer use XTAL OUTPUT INPUT Capture USB device SDIO 2.0 Device External 32K External 32K...
-
Page 11: Hardware Configuration
Ameba-Z DEV01 1V0 Hardware configuration 5.1. LOGUART PIN SEL Table 3 Ameba-Z LOGUART EFUSE EFUSE LOGUART PIN EFUSE 0x19[6]=0 GPIOA_29 & GPIOA_30 EFUSE NOT PG EFUSE PG EFUSE 0x19[6]=0 GPIOA_29 & GPIOA_30 EFUSE 0x19[6]=1 GPIOA_16 & GPIOA_17 5.2. SWD & LOGUART Figure 2 Ameba-Z SWD &... -
Page 12: Cmsis-Dap & Loguart
Ameba-Z DEV01 1V0 5.3. CMSIS-DAP & LOGUART RTL-AMEBAZ_DEV01 supports CMSIS-DAP debugger. It requires installing “serial to USB driver” at first. Serial to USB driver can be found in tools\serial_to_usb\mbedWinSerial_16466. Connect board to the PC with micro-USB cable. Figure 3 Ameba-Z CMSIS-DAP... -
Page 13: Dap Firmware Update
Ameba-Z DEV01 1V0 DAP Firmware update In DAP mode, the DAP firmware can be updated. Holding TGT_NRESET button (J24, red-circled) then press nRESET button (J17, blur-circled). Then the DAP mode window will show up. Figure 4 Ameba-Z CMSIS-DAP Firmware update DAP window will show up when entering DAP mode. -
Page 14: Reference Electrical Schematics
Ameba-Z DEV01 1V0 Reference electrical schematics 7.1. DC power Figure 5 Ameba-Z Schematics DC-Power 14/19... -
Page 15: Dap
Ameba-Z DEV01 1V0 7.2. DAP Figure 6 Ameba-Z Schematics DAP 15/19... -
Page 16: Ft232
Ameba-Z DEV01 1V0 7.3. FT232 Figure 7 Ameba-Z Schematics FT-232 16/19... -
Page 17: Gpio Group And Function-Mux
Ameba-Z DEV01 1V0 7.4. GPIO GROUP and Function-Mux Figure 8 Ameba-Z Schematics GPIO Group & Function-Mux 17/19... -
Page 18: Swd
Ameba-Z DEV01 1V0 7.5. SWD Figure 9 Ameba-Z Schematics SWD 7.6. UART LOG Selection Figure 10 Ameba-Z Schematics UART-LOG Selection 18/19... -
Page 19: 8710Bn Module
Ameba-Z DEV01 1V0 7.7. 8710BN module Figure 11 Ameba-Z Schematics 8710BN module 19/19...
