6.2

Maintenance

6.2.1

Tools and consumables

● Torque wrench
(depending on the screw used and the material of the mounting fixture)
● Threadlocker
(for example Loctite 274 depending on the location and purpose of use)
● Distance gauge supplied
6.2.2

Checking the measuring system

 Check the MiniCODER and target wheel regularly for damage.
 Regularly check whether there are any foreign bodies in the installation space of
the MiniCODER.
6.2.3

Checking the MiniCODER fastening

Regularly check that the screws are tight.
 Insert the distance gauge into the installation space between the MiniCODER and
the target wheel.
 If necessary, unscrew the two screws counterclockwise and apply threadlocker to
the threads of the two screws.
 Screw the two screws clockwise into the mounting fixture and tighten to a maxi-
mum tightening torque of 2.5 Nm.
 Remove the distance gauge.
Maintenance ist completed.
6.3

Cleaning

6.3.1

Consumables

● Lint free cloth
● Non-corrosive cleaning agent
6.3.2

Cleaning the MiniCODER

NOTICE Penetration of foreign bodies or liquids!
● Do not use a pressure washer.
 Clean the MiniCODER regularly with a damp, lint-free cloth.
Cleaning ist completed.
