5 Mounting and connection
5.4

Mounting and connecting the MiniCODER

Magnetic field!
CAUTION
● Exercise caution when approaching the product to metallic objects.
● Hold the product in such a way as to avoid crushing of fingers or
skin.
NOTICE
Incorrect handling of measuring surface!
● Avoid sudden contact between the measuring surface and other ob-
jects.
● Do not destroy or remove the protective layer on the measuring sur-
face.
● Observe the assembly sequence.
NOTICE Incorrect handling of connection components!
● Observe minimum bending radiuses.
5.4.1

Accessories, tools and consumables

● 2 M4 screws (recommendation: DIN 912 M4×10) with spring washers and
washers
● Torque wrench
(depending on the screw used and the material of the mounting fixture)
● Threadlocker
(for example Loctite 274 depending on the location and purpose of use)
● Distance gauge supplied
● Lint-free cloth, moistened with a non-corrosive cleaning agent
● As required: Mobile service unit
● Accessories and tools for connecting the MiniCODER to the
higher level control system
(depending on the connection type)
82
Mounting and connecting the MiniCODER Lenord+Bauer
GEL 2444M
