3 Description
3.3.5

GEL 2444M P

Configuration
The resolution is dependent of the number of teeth of the target wheel and the maxi-
mum speed. The maximum configurable resolution is 19 bits/0.00068° (524288 posi-
tions per revolution).
Factory settings
Designation
Interpolation per
tooth cycle
Target wheel tooth
number
The maximum speed of the MiniCODER is limited by the internal electronics. The
maximum mechanical speed depends on the selection of the target wheel.
Calculation of the maximum rotational speed
Maximum rotational speed =
3.3.6

Functions with the mobile service unit

The MiniCODER can be tested and configured with the GEL 211CST4␣2M mobile
service unit.
The following tests are available:
● MiniCODER functional test
● Target wheel functional test
The following configurations are possible:
● Change the resolution.
● Change the number of teeth at the target wheel.
● Determine the parameters to be set on the higher level control system.
74
Description of GEL 2444M
GEL
2444M␣P␣3␣␣␣␣␣
512
256
2.7 • 10
Number of teeth • Interpolation
␣␣␣␣␣␣␣␣␣
GEL
2444M␣P␣4␣␣␣␣␣
512
192
9
min
Lenord+Bauer
GEL
2444M␣P␣5␣␣␣␣␣
512
150
-1
GEL 2444M
