5.4.4

Checking and configuring the measuring system

The measuring system can be tested and configured with the mobile service unit.
Connection of the MiniCODER and operation of the mobile service unit are
described in the operating instructions for the mobile service unit (reference
documents → page
 Connect the MiniCODER to the mobile service unit.
Configuration of the measuring system if necessary
 Enter the tooth number.
 Enter the resolution.
Checking the measuring system
 Turn the target wheel and check the function of the MiniCODER and target wheel.
 Check assignment of the direction of rotation.
 If necessary, start a new calibration process, check the air gap and repeat the in-
stallation.
 Ensure that no error message is displayed (Alarm and warning table
 Remove the mobile service unit.
The function test is completed.
5.4.5

Connecting the MiniCODER electrically

 Make sure that the product all connection components are de-energized.
 GEL 244 M
nectors (connection and tools depend on the connectors used).
Connect the connector correctly to the connection cable of the MiniCODER ac-
cording to the assignment
tions (→ page 67f).
 GEL 244 M
 Lay the cable in accordance with the EMC instructions
ing radiuses (Accessories
 Connect the MiniCODER to the higher level control system and the power supply.
Connection ist completed.
GEL 2444M
Mounting and connecting the MiniCODER
55).
K : Remove the test connector and connect suitable con-
(→ page 97) and in compliance with the EMC instruc-
Z : Connect the adapter cable (Accessories
→ page 96, Technical data MiniCODER
5 Mounting and connection
→ page
→ page
(→ page 67f) and the bend-
→ page
72).
96).
94).
