Lenord+Bauer
ESD
Evaluation electronics
Implants
Measuring scale
MiniCODER
Mz×y
Product
Target wheel
Usage Information
GEL 2444M
Conventions
Abbreviation for "Electrostatic Discharge" (ESD)
General designation for a control system for machine tools
or a higher level control system
General designation for active medical implants (for exam-
ple, pacemakers), passive medical implants (for example,
heart valves) or medical devices worn on the body (for ex-
ample, insulin pumps).
General designation for target wheel, rack or slotted disk
These operating instructions are primarily concerned with
target wheel applications. The same applies to other mea-
suring scales.
Designation for the product family of the GEL 24xx product
groups.
This designation is also used as a general designation for
an encoder kit of the product group.
Marking of metric thread
M Abbreviation for metric thread
z Thread size in millimeters
y Thread length in millimeters (for screw specifications)
General designation for an encoder kit of the product fami-
ly.
Target wheel for measuring tasks, general designation:
Measuring scale
The term "Usage Information" refers to any information
that is needed to use the product.
Usage information includes, for example, software, docu-
ments, training, or display indications.
