Cable the Roving Edge Device
Cable the Roving Edge Device
Use the following diagram to locate connectors on the rear of the Roving Edge Device 2 as you connect cables in this
procedure.
Note:
To meet MIL-STD-461 Rev G RE102 requirements, all Ethernet network
cables attached to the Roving Edge Device must be CAT8 rated.
1. Connect the provided USB-to-DB-9 Ethernet cable from the device DB-9 serial console port to a USB connector
on your controlling host, such as a laptop.
a. Use a 10GBaseT RJ-45 Ethernet cable to connect the device Ethernet port to your Ethernet switch.
b. Use the provided USB-to-DB-9 serial cable to connect the device serial port to a laptop.
2. Connect the provided power cord to the device power receptacle and to your power source, but don't power on the
device yet.
