SmartHandle AX Advanced 105/145
9. Replacing the batteries
NOTE
Malfunctions due to poor contact or different discharge
Contact surfaces that are too small/contaminated or different discharged
batteries can lead to malfunctions.
1. Only use batteries that are approved by SimonsVoss.
2. Do not touch the contacts of the new batteries with your hands.
3. Use clean and grease-free gloves.
4. Always replace all batteries at the same time.
ü Special tool at hand.
ü Gloves at hand.
1. Insert the special tool into the cover inlay on the electronics side.
60
2. Use the special tool to carefully bend the cover inlay upwards.
61
3. Slide the cover downwards.
62
9 Cover unlocked.
4. Remove the cover.
63
5. Use the special tool to detach the battery module clip.
64
6. Remove the battery module.
65
7. Use the special tool to detach the battery clip.
66
8. Remove the upper batteries.
67
9. Carefully bend the intermediate spring to one side.
10. Remove the lower batteries.
68
11. Insert two new batteries with the positive terminals next to each other
(type CR2450).
69
Intermediate spring visible above the lower batteries.
9
12. Insert two new batteries with the positive terminals next to each other
(type CR2450).
70
13. Reattach the battery clip.
71
14. Put the battery module back into the module support.
72
15. Use the special tool to reattach the battery module clip.
73
9 SmartHandle AX Advanced will beep three times.
16. Place the cover on top of the fastening plate.
74
17. Fold down the cover.
75
18. Push the cover against the door, sliding it upwards at the same time.
76
9 Cover snaps into place.
EN
19. Press the inlay into place.
77
9 Batteries are now replaced.

10. Technical data

Operating temperature range
Battery type
Battery manufacturer
IP protection rating
Radio emissions
15.24 kHz - 72.03 kHz
Only for item numbers: SV-
S3.*AM.G2*, SV-S3.*A.G2*, SI-
S3.*LN*
13.560006 MHz - 13.560780 MHz
Only for item numbers: SV-
S3.*AM.G2*, SV-S3.*A.G2*, SI-
S3.*M.WO*, SI-S3.*LN*
868.000 MHz - 868.600 MHz /
869.700 MHz - 870.000 MHz
Only for item numbers: SI-
S3.*M.WO*, SI-S3.*LN*
2402 MHz - 2480 MHz
Only for item numbers: SV-
S3.*AM.G2*, SV-S3.*A.G2*, SI-
S3.*M.WO*, SI-S3.*LN*

11. Declaration of conformity

The company SimonsVoss Technologies GmbH hereby declares that the
articles (SI-S3.*M.VCN*, SV-S3.*M.G2*, SV-S3.*AM.G2*, SV-S3.*A.G2*, SI-
S3.*M.WO*, SI-S3.*LN*) comply with the following guidelines:
2014/53/EU -RED-

or for the UK: UK statutory 2017 No. 1206 -Radio equipment-
2011/65/EU -RoHS-

or for the UK: UK statutory 2012 No. 3032 -RoHS-
The full text of the EU Declaration of conformity is available at the following
www.simons-voss.com/en/certificates.html
internet address:
The full text of the UK Declaration of conformity is available at the following
www.simons-voss.com/en/certificates.html
internet address:
12. Help and other information
Information material/documents
https://www.simons-voss.com/en/documents.html
https://www.smartintego.com/int/home/infocenter/documentation
Declarations of conformity
https://www.simons-voss.com/en/certificates.html
Information on disposal
 Do not dispose the device (SI-S3.*M.VCN*, SV-S3.*M.G2*, SV-
S3.*AM.G2*, SV-S3.*A.G2*, SI-S3.*M.WO*, SI-S3.*LN*) in the
household waste. Dispose of it at a collection point for electronic waste
as per European Directive 2012/19/EU.
Recycle defective or used batteries in line with European Directive

2006/66/EC.
 Observe local regulations on separate disposal of batteries.
 Take the packaging to an environmentally responsible recycling point.
78
9. Replacing the batteries
-25 °C to +60 °C
4x CR2450 3V lithium
Murata

Panasonic

Varta

Up to IP66 (WP variant)
10 dBµA/m (3 m distance)
1.04 dBµA/m (3 m distance)
<25 mW ERP
2.5 mW
.
.
37 / 64
