SmartHandle AX Advanced 105/145
*X
42
PH2
*S
43
M5×35
*M min.
44
M5×40
*M max.
45
M5×50
*L min.
46
M5×60
*L max.
47
M5×70
48
PH2
Abbildungen/Images
7. Installing the fitting
17 / 64
