Installing The Fitting - Simons Voss Technologies SmartHandle AX Advanced 105 Quick Manual

SmartHandle AX Advanced 105/145
 Adapter sleeve, 8.5 mm spindle
Adapter sleeve, 10 mm spindle

4. Structure
1
5. Prepare door (drilling template)
Pin or scriber at hand.
ü
Drill at hand.
ü
Suitable drill bit at hand (Ø 7 mm).
ü
ü PH2 screwdriver at hand.
1. Insert the spindle into the mortise lock.
2
2. Place the drilling template on the spindle.
3
3. Align the drill template vertically using the printed scale.
4. Mark the drill holes with mark 1.
4
5. Remove the drilling template and rotate it 180 degrees.
5
6
6. Place the drilling template on the spindle.
7
7. Align the drill template vertically using the printed scale.
8. Mark the drill hole with mark 2.
8
9. Remove the drilling template and spindle.
9
10
10. Remove the mortise lock.
11
11. Drill the required holes.
12
12. Fit the mortise lock.
13
6. For door thickness X: have the
threaded rods and spindle ready at hand
ü Caliper gauge at hand.
ü Saw at hand.
ü PH2 screwdriver at hand.
1. Measure the door thickness.
14
2. For door thickness X: screw the 50 mm screws, threaded sleeves and
threaded rods together.
15
3. For X: mark the sawing points on the threaded rods and spindle.
16
17
4. For X: Use a suitable saw to cut the threaded rods and spindle.
18

7. Installing the fitting

ü Door pre-drilled.
ü PH2 screwdriver at hand.
EN
ü TX15 screwdriver at hand.
Caliper gauge at hand.
ü
1. For non-MO: insert the blank cylinder.
NOTE
Feed the blank cylinder into the hole using a screwdriver
It is difficult to position the blank cylinder correctly, especially in thick doors.
1. Insert a screwdriver into the hole in the blank cylinder.
2. Position the blank cylinder using the screwdriver.
19
20
2. For non-MO: screw the blank cylinder firmly into position.
21
3. Insert the spindle protection tube into the fixing plate.
22
4. For 7 mm spindle: Insert the adapter shoe into the spindle mount on the
module support.
23
5. Insert the module support into the fastening plate.
24
6. Slide the module support upwards.
25
Module support snaps into place.
9
7. Screw the threaded sleeves onto the fixing plate threaded bolts.
8. Fasten the module support to the fastening plate (PH2) with the 12 mm
screws.
26
27
9. Insert the module support with the fastening plate into the outer side of
the door.
NOTE
Reducing sleeves for existing 14 mm holes
Existing 14 mm holes make it difficult to secure the SmartHandle AX Ad-
vanced.
Insert the supplied silicone reducing sleeves into the existing holes to re-

duce the backlash.
10. For 7 mm spindle: Place the adapter sleeve in the inside handle in such a
way that the recess faces the grub screw.
28
11. Determine the required direction of rotation for your inside handle.
12. Insert the spring element appropriately.
29
30
13. Place the underlay in the inner handle unit.
31
14. Screw the inside handle together with the threaded sleeves and 10 mm
screws onto the fixing plate (2.5 mm hex key and PH2).
32
33
15. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre
of the spindle. Use a punch and hammer to make an indent in the ad-
apter sleeve to prevent it from slipping.
34
