8. Removing the fitting (105/145)
35
16. Measure the total length of the spindle.
36
17.
Locate the inside of the spindle (four-edge end up to the centre of the
first groove = 26 mm).
18. Use the table to determine the position of the O-ring.
37
Door thickness
Size
(mm)
S
38 – <41
S
38 – <41
S
41 – <46
S
41 – <46
S
46 – <51
S
51 – 53
M
51 – <56
M
51 – <56
M
56 – <61
M
56 – <61
M
61 – <66
M
61 – <66
M
66 – <71
M
71 – 73
L
71 – <76
L
71 – <76
L
76 – <81
L
76 – <81
L
81 – <86
L
81 – <86
L
86 – <91
L
91 – 93
XL
91 – 176
19. Slide the O-ring onto the calculated groove.
38
20. Insert the spindle into the door with the ring-free side as far as it will go.
39
21.
Measure the door thickness.
40
Size
Door thickness (mm)
S
38 – 53
M
51 – 63
M
62 – 73
L
71 – 83
L
82 – 93
X
91 – 176
22. Determine what screws are required for the door thickness measured.
23. For X: Insert the screws through the inner fastening plate and screw
them together with the threaded sleeve and threaded rod.
41
42
36 / 64
Spindle length
Ring position
(mm)
94
2
104
4
94
1
104
3
104
2
104
1
114
3
124
5
114
2
124
4
114
1
124
3
124
2
124
1
134
3
144
5
134
2
144
4
134
1
144
3
144
2
144
1
O-ring is located 30–35 mm from
the cut end of the spindle.
Screws
M5×35
M5×40
M5×50
M5×60
M5×70
M5 X
SmartHandle AX Advanced 105/145
24. Screw the inner part and the outer part (PH2) with the required screws.
NOTE
Reducing sleeves for existing 14 mm holes
Existing 14 mm holes make it difficult to secure the SmartHandle AX Ad-
vanced.
Insert the supplied silicone reducing sleeves into the existing holes to re-
duce the backlash.
43
44
45
46
47
48
25. Fasten the inner handle grub screw firmly (TX15).
49
26. Place a cover with the notch facing downwards onto the escutcheon
base.
50
27. Place the cover on top of the fastening plate.
51
28. Fold down the cover.
52
29. Slide the cover upwards.
53
30. Press the inlay into place.
54
31.
Fit the outside handle.
55
32. Use the grub screw to fasten the outer handle (TX15) into position.
56
9
SmartHandle AX Advanced fully installed.
57
8. Removing the fitting (105/145)
ü
1.5 mm hexagonal wrench available.
1.
Remove the fitting in the reverse order to installation.
2.
Loosen the cover by bending the inlay outwards using the special tool.
3.
Insert a 1.5 mm hex key into the hole in the spindle mount in the module
support.
58
4.
Bend the hex key to the side where the hole is located while pulling on
the outside handle.
59
9
SmartHandle AX Advanced is now removed.
