Simons Voss Technologies SmartHandle AX Advanced Series Quick Manual page 8
Conventional installation
Hide thumbs
Also See for SmartHandle AX Advanced Series:
- Quick manual (53 pages) ,
- Quick manual (57 pages) ,
- Quick manual (61 pages)
Advertisement
Available languages
Available languages
6. For door thickness X: have the threaded rods and spindle ready
at hand
6. For door thickness X: have the threaded rods and spindle ready at hand
*X
14
*X
15
PH2
*X
16
Door thickness - 10 mm (±2 mm)
*X
17
Door thickness + 63 mm (±2 mm)
8 / 68
PH2
SmartHandle AX Advanced Conventional installa-
Abbildungen/Images
tion SH3062/FR195
