SmartHandle AX Advanced Conventional installa-
tion SH3062/FR195
Size Door thickness (mm)
S 37 – 48
S 47 – 58
M 57 – 68
M 67 – 78
L 77 – 88
L 87 – 98
X 97 – 171
10. Determine what screws are required for the door thickness measured.
11. Insert the module support with the fastening plate into the outer side of
the door.
30
12. For X: Insert the screws through the inner fastening plate and screw
them together with the threaded sleeve and threaded rod.
31
32
13. Screw the inner fixing plate to the outer part (PH2) with the required
screws.
33
34
35
36
37
38
39
14. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre
of the spindle. Use a punch and hammer to make an indent in the ad-
apter sleeve to prevent it from slipping.
40
41
15. Measure the total length of the spindle.
42
16. Locate the inside of the spindle (four-edge end up to the centre of the
first groove = 26 mm).
17. Use the table to determine the position of the O-ring.
43
EN
Screws
Size
M5×35
S
M5×45
S
M5×50
S
M5×60
S
M5×70
S
M5×80
S
M5 X
S
S
M
M
M
M
M
M
M
M
L
L
L
L
L
L
L
L
XL
18. Slide the O-ring onto the calculated groove.
19. Insert the spindle into the door with the ring-free side as far as it will go.
20. Insert the filling profile onto the inner fixing plate.
21.
22. Determine the required direction of rotation for your inside handle.
23. Insert the spring element appropriately.
24. Place the inside handle unit on the spindle.
25. Use the 12 mm screws to fasten the inner handle unit onto the fixing
26. Place the cover on top of the fastening plate.
27. Fold down the cover.
28. Slide the cover upwards.
Door thickness
(mm)
37 – <41
37 – <41
41 – <46
41 – <46
46 – <51
46 – <51
51 – <56
56 – 58
57 – <61
57 – <61
61 – <66
61 – <66
66 – <71
66 – <71
71 – <76
76 – 78
77 – <81
77 – <81
81 – <86
81 – <86
86 – <91
86 – <91
91 – <96
96 – 98
97 – 171
44
45
46
For 7 mm spindle: Place the adapter sleeve in the inside handle in such a
way that the recess faces the grub screw.
47
48
49
plate (PH2).
24
51
52
53
54
7. Installing the fitting
Spindle length
Ring position
(mm)
104 3
114 5
104 2
114 4
104 1
114 3
114 2
114 1
124 3
134 5
124 2
134 4
124 1
134 3
134 2
134 1
144 3
154 5
144 2
154 4
144 1
154 3
154 2
154 1
O-ring is located 30–35 mm from
the cut end of the spindle.
