Simons Voss Technologies SmartHandle AX Advanced Series Quick Manual page 13

SmartHandle AX Advanced Conventional installa-
tion SH3062/FR195
Size
S
S
M
M
L
L
X
30
*X
31
M5 X
*X
32
PH2
*S min.
33
M5×35
Abbildungen/Images
Door thickness (mm)
37 – 48
47 – 58
57 – 68
67 – 78
77 – 88
87 – 98
97 – 171
7. Installing the fitting
Screws
M5×35
M5×45
M5×50
M5×60
M5×70
M5×80
M5 X
13 / 68
