7. Installing the fitting
*S max.
34
M5×45
*M min.
35
M5×50
*M max.
36
M5×60
*L min.
37
M5×70
*L max.
38
M5×80
39
PH2
*8,5 mm/10 mm
40
14 / 68
SmartHandle AX Advanced Conventional installa-
Abbildungen/Images
tion SH3062/FR195
