7. Installing the fitting
Size
S
S
S
S
S
S
S
S
M
M
M
M
M
M
M
M
L
L
L
L
L
L
L
L
XL
44
16 / 68
Door thickness (mm)
37 – <41
37 – <41
41 – <46
41 – <46
46 – <51
46 – <51
51 – <56
56 – 58
57 – <61
57 – <61
61 – <66
61 – <66
66 – <71
66 – <71
71 – <76
76 – 78
77 – <81
77 – <81
81 – <86
81 – <86
86 – <91
86 – <91
91 – <96
96 – 98
97 – 171
SmartHandle AX Advanced Conventional installa-
Spindle length (mm)
104
114
104
114
104
114
114
114
124
134
124
134
124
134
134
134
144
154
144
154
144
154
154
154
O-ring is located 30–35 mm from the cut end of the spindle.
tion SH3062/FR195
Ring position
3
5
2
4
1
3
2
1
3
5
2
4
1
3
2
1
3
5
2
4
1
3
2
1
Abbildungen/Images
