AX Advanced can engage and open the door in question when an authorised identification medium is held against it. The corresponding authorisations need to be issued using an electronic locking plan. SmartHandle AX Advanced may only be used for locking and unlocking doors. No other use is permitted.
SmartHandle AX Advanced 2. General safety instructions (Manual) 7 / 449 2. General safety instructions Signal word: Possible immediate effects of non-compliance WARNING: Death or serious injury (possible, but unlikely) CAUTION: Minor injury IMPORTANT: Property damage or malfunction NOTE: Low or none...
Page 8
SmartHandle AX Advanced 2. General safety instructions (Manual) 8 / 449 IMPORTANT Damage resulting from electrostatic discharge (ESD) when enclosure is open This product contains electronic components that may be damaged by electrostatic discharges. 1. Use ESD-compliant working materials (e.g. Grounding strap).
Page 9
SmartHandle AX Advanced 2. General safety instructions (Manual) 9 / 449 NOTE Intended use SimonsVoss-products are designed exclusively for opening and closing doors and similar objects. Do not use SimonsVoss products for any other purposes. Malfunctions due to poor contact or different discharge Contact surfaces that are too small/contaminated or different discharged batteries can lead to malfunctions.
SmartHandle AX Advanced 4. Meaning of the text formatting (Manual) 11 / 449 4. Meaning of the text formatting This documentation uses text formatting and design elements to facilitate understanding. The table explains the meaning of possible text formatting: Example...
SmartHandle AX Advanced 5. Versions (Manual) 12 / 449 5. Versions 5.1 Mechanical Override (MO) Profiles [ 12] You can install an additional locking cylinder (see ). This makes it possible to bypass the electronic door opening and to open the door with an alternative key (mechanical secondary locking device).
SmartHandle AX Advanced 5. Versions (Manual) 15 / 449 Installation vari- Fastening Boreholes used Description ants Escutcheon in- You fasten the stallation (RMO) SmartHandle AX 117] Advanced to the adapter plate. Installation of This is only rosettes screwed to the...
Page 16
SmartHandle AX Advanced 5. Versions (Manual) 16 / 449 Door thick- brevi- Versions Distance ness ation Euro profile cylinders: S: 39 - 61 mm 70 mm M: 59 - 81 mm 72 mm L: 79 - 75 mm 101 mm 78 mm 85 mm 88 mm Long backplate 90 mm...
Page 17
SmartHandle AX Advanced 5. Versions (Manual) 17 / 449 Door thick- brevi- Versions Distance ness ation S: 39 - 55 mm M: 54 - Euro profile cylinders: 75 mm Security fitting (ES3) 72 mm L: 74 - 92 mm 95 mm X: 93 - 168 mm...
Page 18
SmartHandle AX Advanced 5. Versions (Manual) 18 / 449 Door thick- brevi- Versions Distance ness ation Euro profile cylinders: S: 37 - 58 mm 70 mm M: 57 - 72 mm 78 mm 75 mm L: 77 - 98 mm 78 mm 85 mm 88 mm Conventional installation 90 mm...
Page 19
SmartHandle AX Advanced 5. Versions (Manual) 19 / 449 Door thick- brevi- Versions Distance ness ation S: 38 - 53 mm Euro profile cylinders: M: 51 - 73 mm Conventional mount- 72 mm ing105-145 L: 71 - 93 mm 92 mm X: 91 - 176 mm...
Page 20
SmartHandle AX Advanced 5. Versions (Manual) 20 / 449 Door thick- brevi- Versions Distance ness ation S: 32 - 60 mm for: BKS, CISA M: 51 - 80 mm Euro profile cylinders: for: BKS, Panic with narrow cover and CISA 72 mm backplate L: 71 - 92 mm...
Page 21
SmartHandle AX Advanced 5. Versions (Manual) 21 / 449 Door thick- brevi- Versions Distance ness ation Euro profile cylinders: S: 32 - 54 mm 70 mm M: 52 - 72 mm 74 mm 75 mm L: 72 - 94 mm 78 mm 85 mm 88 mm Installation of rosettes 90 mm...
Mechanical Override (MO) [ 12] secondary locking device ( ). In this case, you may lock the door using an additional cylinder (see Profiles [ 12] 5.6 Spindle socket in mortise lock You receive the SmartHandle AX Advanced for the following spindle sockets:...
Page 23
Order the fire-resistant version of SmartHandle AX Ad- 9 mm vanced for fire doors and emergency exit locks. With the 8 mm push-on sleeve (already included in SmartHandle AX Advanced the scope of delivery for 10 mm version): 10 mm 7 mm 8 mm 8.5 mm...
SmartHandle AX Advanced 5. Versions (Manual) 24 / 449 5.7 Network You can equip the SmartHandle AX Advanced with a network node at any time (see LockNode [ 372] ). You do not need to replace any components. Instead, simply insert the network node card into the slot provided.
Page 25
SmartHandle AX Advanced 5. Versions (Manual) 25 / 449 Letter Description L-shaped G (mitred) В U-shaped R (round curved) U-shaped G (mitred) U-shaped, rounded, offset U-shape (rectangular and offset)
45°) Delivery without handle (for use with adapter sets and Third-party handle adapter (FSB) third-party handles, see 391] 5.9 Surface finishes/colour The SmartHandle AX Advanced is available in different finishes and colours. So it blends perfectly into its surroundings. Silver/anthracite...
5. Versions (Manual) 29 / 449 Brass/deep black 5.10 Reader technology Depending on the equipment, your SmartHandle AX Advanced supports the following scanning methods: Active (25 kHz, e.g. transponder) - initial programming is also passively possible Passive (MIFARE – Classic, Plus,...
SmartHandle AX Advanced for design reasons. 5.11 Access control (ZK) and time zone control Access control With this option, your can save SmartHandle AX Advanced up to 1,500 access events. A saved entry consists of: Date ...
SmartHandle AX Advanced 6. Installation (Manual) 32 / 449 6.1.3 Prepare door (drilling template) ü Pin or scriber at hand. ü Drill at hand. Suitable drill bit at hand (Ø 7 mm). ü Countersink at hand. ü ü Ruler at hand.
Page 33
SmartHandle AX Advanced 6. Installation (Manual) 33 / 449 2. Measure the distance (gap between the spindle and cylinder axes of ro- tation).
Page 34
SmartHandle AX Advanced 6. Installation (Manual) 34 / 449 3. Fit the mortise lock.
Page 35
SmartHandle AX Advanced 6. Installation (Manual) 35 / 449 4. Insert the spindle into the mortise lock.
Page 36
SmartHandle AX Advanced 6. Installation (Manual) 36 / 449 5. Place the drilling template on the spindle from the inner side. Inner side 6. Align the drill template vertically using the printed scale.
Page 37
SmartHandle AX Advanced 6. Installation (Manual) 37 / 449 7. Mark the points to be drilled on the inner side of the door.
Page 39
SmartHandle AX Advanced 6. Installation (Manual) 39 / 449 9. Place the drilling template onto the square from the outside. Outer side 10. Align the drill template vertically using the printed scale.
Page 40
SmartHandle AX Advanced 6. Installation (Manual) 40 / 449 11. Mark the points where the door is to be drilled on the door.
SmartHandle AX Advanced 6. Installation (Manual) 46 / 449 6.1.4 For door thickness X: prepare the spindle ü Saw at hand. ü Caliper gauge at hand. 1. Measure the door thickness. 2. For X: mark the sawing point on the spindle.
SmartHandle AX Advanced 6. Installation (Manual) 47 / 449 6.1.5 Installing the fitting ü Door pre-drilled. ü Blind rivet nut pliers at hand. PH2 screwdriver at hand. ü TX15 screwdriver at hand. ü ü Caliper gauge at hand. 1. Fit the blind rivet nuts into the pre-drilled holes.
Page 48
SmartHandle AX Advanced 6. Installation (Manual) 48 / 449 2. For non-MO: insert the blank cylinder. NOTE Feed the blank cylinder into the hole using a screwdriver It is difficult to position the blank cylinder correctly, especially in thick doors.
Page 49
SmartHandle AX Advanced 6. Installation (Manual) 49 / 449 3. For non-MO: screw the blank cylinder firmly into position. 4. Use the 12 mm screws to fix the fastening plate onto the outer side of the door (PH2) with the tip facing upwards.
Page 51
SmartHandle AX Advanced 6. Installation (Manual) 51 / 449 5. Insert the module support into the fastening plate.
Page 52
SmartHandle AX Advanced 6. Installation (Manual) 52 / 449 6. Slide the module support upwards. Module support snaps into place. 7. Use the 18 mm screws to fix the module support onto the fastening plate (PH2). M5×18...
Page 54
SmartHandle AX Advanced 6. Installation (Manual) 54 / 449 8. Place the cover on top of the fastening plate.
Page 55
SmartHandle AX Advanced 6. Installation (Manual) 55 / 449 9. Fold down the cover.
Page 56
SmartHandle AX Advanced 6. Installation (Manual) 56 / 449 10. Push the cover against the door, sliding it upwards at the same time. Cover snaps into place.
Page 57
SmartHandle AX Advanced 6. Installation (Manual) 57 / 449 11. Press the inlay into place. 12. Fit the outside handle. 13. Determine the required direction of rotation for your inside handle. 14. Insert the spring element appropriately.
Page 58
SmartHandle AX Advanced 6. Installation (Manual) 58 / 449 15. Place the underlay in the inside handle unit. 16. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre of the spindle. Use a punch and hammer to make an indent in the ad-...
Page 59
SmartHandle AX Advanced 6. Installation (Manual) 59 / 449 17. Measure the total length of the spindle. 18. Locate the inside of the spindle (four-edge end up to the centre of the first groove = 26 mm). 19. Use the table to determine the position of the O-ring.
Page 61
SmartHandle AX Advanced 6. Installation (Manual) 61 / 449 20.Slide the O-ring onto the calculated groove. 21. Insert the spindle into the door with the ring-free side as far as it will go. 22. Place the inside handle unit on the spindle.
Page 62
SmartHandle AX Advanced 6. Installation (Manual) 62 / 449 23. Use the 22 mm screws to fasten the inside handle unit onto the inner side of the door (PH2). M5×22 24.Use the 16 mm screws to fasten the cylinder rosette on the inner side of the door (PH2).
Page 63
SmartHandle AX Advanced 6. Installation (Manual) 63 / 449 25. Use the grub screws to tighten both handles (TX15). 26.Place the cylinder plate and the inside handle cover onto the escut- cheons. SmartHandle AX Advanced fully installed.
1. Do not press on the screws when fastening the module support into place. 2. Place a finger on the ends of the threaded sleeves to hold them in place while screwing. 6.2.2 Scope of delivery SmartHandle AX Advanced Long backplate/short backplate Special tool Quick guide ...
SmartHandle AX Advanced 6. Installation (Manual) 66 / 449 6.2.4 Prepare door (drilling template) ü Pin or scriber at hand. ü Drill at hand. Suitable drill bit at hand (Ø 7 mm). ü PH2 screwdriver at hand. ü 1. Insert the spindle into the mortise lock.
Page 67
SmartHandle AX Advanced 6. Installation (Manual) 67 / 449 2. Place the drilling template on the spindle. 3. Align the drill template vertically using the printed scale.
Page 68
SmartHandle AX Advanced 6. Installation (Manual) 68 / 449 4. Mark the points to be drilled on the door (backplate: centre/top; short backplate: centre/bottom).
Page 69
SmartHandle AX Advanced 6. Installation (Manual) 69 / 449 5. Remove the drilling template and spindle.
SmartHandle AX Advanced 6. Installation (Manual) 73 / 449 6.2.5 For door thickness X: have the threaded rods and spindle ready ü Saw at hand. ü Caliper gauge at hand. PH2 screwdriver at hand. ü 1. Measure the door thickness.
SmartHandle AX Advanced 6. Installation (Manual) 74 / 449 4. For X: Use a suitable saw to cut the threaded rods and spindle. 6.2.6 Installing the fitting ü Door pre-drilled. PH2 screwdriver at hand. ü ü TX15 screwdriver at hand.
Page 75
SmartHandle AX Advanced 6. Installation (Manual) 75 / 449 2. For non-MO: screw the blank cylinder firmly into position. 3. For short backplate: insert the mounting disc into the smaller fastening plate.
Page 76
SmartHandle AX Advanced 6. Installation (Manual) 76 / 449 4. Insert the sleeve nuts into the smaller fastening plate (backplate: centre/top; short backplate: centre/bottom).
Page 77
SmartHandle AX Advanced 6. Installation (Manual) 77 / 449 5. For 7 mm spindle: Insert the adapter shoe into the spindle mount on the module support.
Page 78
SmartHandle AX Advanced 6. Installation (Manual) 78 / 449 6. Insert the module support into the fastening plate.
Page 79
SmartHandle AX Advanced 6. Installation (Manual) 79 / 449 7. Slide the module support upwards. Module support snaps into place. 8. Fasten the module support to the fastening plate (PH2) with the 12 mm screws. M5×12...
Page 80
SmartHandle AX Advanced 6. Installation (Manual) 80 / 449 9. Measure the door thickness.
Page 82
SmartHandle AX Advanced 6. Installation (Manual) 82 / 449 14. Use the required screws to fix the larger fastening plate onto the mod- ule support with the smaller fastening plate (PH2, long backplate: centre/top; short backplate: centre/bottom). M5×35 M5×45 M5×50 M5×60...
Page 84
SmartHandle AX Advanced 6. Installation (Manual) 84 / 449 15. For 7 mm spindle: Place the adapter sleeve in the inside handle in such a way that the recess faces the grub screw. 16. Determine the required direction of rotation for your inside handle.
Page 85
SmartHandle AX Advanced 6. Installation (Manual) 85 / 449 18. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre of the spindle. Use a punch and hammer to make an indent in the ad- apter sleeve to prevent it from slipping.
Page 86
SmartHandle AX Advanced 6. Installation (Manual) 86 / 449 21. Use the table to determine the position of the O-ring.
Page 88
SmartHandle AX Advanced 6. Installation (Manual) 88 / 449 22. Slide the O-ring onto the calculated groove. 23. Insert the spindle into the door with the ring-free side as far as it will go.
Page 89
SmartHandle AX Advanced 6. Installation (Manual) 89 / 449 24.Place the filling profile on the larger fastening plate. 25. Place the inside handle unit on the spindle. 26.Use the 12 mm screws to fasten the inside handle unit onto the fasten- ing plate (PH2).
Page 90
SmartHandle AX Advanced 6. Installation (Manual) 90 / 449 27. Fit the cover for the outer side as follows: 28.Place the cover on top of the fastening plate.
Page 91
SmartHandle AX Advanced 6. Installation (Manual) 91 / 449 29.Fold down the cover.
Page 92
SmartHandle AX Advanced 6. Installation (Manual) 92 / 449 30.Push the cover against the door, sliding it upwards at the same time. Cover snaps into place. 31. Press the inlay into place.
Page 93
SmartHandle AX Advanced 6. Installation (Manual) 93 / 449 32. Fit the cover for the inner side as well. 33. Fit the outside handle.
Page 94
SmartHandle AX Advanced 6. Installation (Manual) 94 / 449 34.Use the grub screws to tighten both handles (TX15). SmartHandle AX Advanced fully installed.
1. Do not press on the screws when fastening the module support into place. 2. Place a finger on the ends of the threaded sleeves to hold them in place while screwing. 6.3.2 Scope of delivery SmartHandle AX Advanced Scandinavian Oval Special tool Quick guide ...
SmartHandle AX Advanced 6. Installation (Manual) 96 / 449 6.3.3 Structure 6.3.4 For door thickness X: have the threaded rods and spindle ready 1. Measure the door thickness.
Page 97
SmartHandle AX Advanced 6. Installation (Manual) 97 / 449 2. For door thickness X: screw the 10 mm screws, threaded sleeves and threaded rods together. 3. For X: mark the sawing points on the threaded rods and spindle. Door thickness - 5 mm (±2 mm) Door thickness + 47 mm (±2 mm)
SmartHandle AX Advanced 6. Installation (Manual) 98 / 449 6.3.5 Installing the fitting ü Door pre-drilled. ü PH2 screwdriver at hand. TX15 screwdriver at hand. ü Caliper gauge at hand. ü ü For MO: cylinder is already fitted. 1. Look at the mortise lock from the outer side and insert the sleeve nuts...
Page 99
SmartHandle AX Advanced 6. Installation (Manual) 99 / 449 2. For 7 mm spindle: Insert the adapter shoe into the spindle mount on the module support. 3. Insert the module support into the fastening plate.
Page 100
SmartHandle AX Advanced 6. Installation (Manual) 100 / 449 4. Slide the module support downwards. Module support snaps into place. 5. Fasten the module support to the fastening plate (PH2) with the 12 mm screws. M5×12...
Page 102
SmartHandle AX Advanced 6. Installation (Manual) 102 / 449 6. Insert the module support with the fastening plate into the outer side of the door. 7. For non-MO: Insert the sleeve nuts into the MO cover.
Page 103
SmartHandle AX Advanced 6. Installation (Manual) 103 / 449 8. Insert the sleeve nuts into the fastening plate. 9. Firmly fasten the cylinder escutcheon to the sleeve nuts (PH2). M4x40 M4x60 M4x80...
Page 104
SmartHandle AX Advanced 6. Installation (Manual) 104 / 449 10. For 7 mm spindle: Place the adapter sleeve in the inside handle in such a way that the recess faces the grub screw. 11. Determine the required direction of rotation for your inside handle.
Page 105
SmartHandle AX Advanced 6. Installation (Manual) 105 / 449 12. Place the interchangeable plate into your inside handle escutcheon as required. 13. Pre-tension the spring element on the interchangeable plate.
Page 106
SmartHandle AX Advanced 6. Installation (Manual) 106 / 449 14. Slide the spring element nose into the slot in the escutcheon. 15. Attach the end of the spring element into the slot in the escutcheon. 16. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre of the spindle.
Page 107
SmartHandle AX Advanced 6. Installation (Manual) 107 / 449 17. Measure the door thickness.
Page 108
SmartHandle AX Advanced 6. Installation (Manual) 108 / 449 18. Measure the total length of the spindle. 19. Locate the inside of the spindle (four-edge end up to the centre of the first groove = 26 mm). 20.Use the table to determine the position of the O-ring.
Page 110
SmartHandle AX Advanced 6. Installation (Manual) 110 / 449 21. Slide the O-ring onto the calculated groove. 22. Insert the spindle into the door with the ring-free side as far as it will go. 23. Place the inside handle unit on the spindle.
Page 111
SmartHandle AX Advanced 6. Installation (Manual) 111 / 449 M4x80 25. Position the cover on the fastening plate at the bottom.
Page 113
SmartHandle AX Advanced 6. Installation (Manual) 113 / 449 27. Slide the cover downwards. Cover snaps into place.
Page 114
SmartHandle AX Advanced 6. Installation (Manual) 114 / 449 28.Press the inlay into place. 29.Fit the outside handle.
Page 115
SmartHandle AX Advanced 6. Installation (Manual) 115 / 449 30.Use the grub screws to tighten both handles (TX15).
Page 116
SmartHandle AX Advanced 6. Installation (Manual) 116 / 449 31. Insert the inside handle cover and, if necessary, the cylinder cover (not for MO version) on the escutcheons. SmartHandle AX Advanced fully installed.
1. Do not press on the screws when fastening the module support into place. 2. Place a finger on the ends of the threaded sleeves to hold them in place while screwing. 6.4.2 Scope of delivery SmartHandle AX Advanced full leaf Special tool Quick guide ...
SmartHandle AX Advanced 6. Installation (Manual) 119 / 449 6.4.4 Prepare door (drilling template) ü Pin or scriber at hand. ü Drill at hand. Suitable drill bit at hand (Ø 8.5 mm). ü Ruler at hand. ü ü PH2 screwdriver at hand.
Page 120
SmartHandle AX Advanced 6. Installation (Manual) 120 / 449 2. Measure the distance (gap between the spindle and cylinder axes of ro- tation).
Page 121
SmartHandle AX Advanced 6. Installation (Manual) 121 / 449 3. Fit the mortise lock.
Page 122
SmartHandle AX Advanced 6. Installation (Manual) 122 / 449 4. Insert the spindle into the mortise lock.
Page 123
SmartHandle AX Advanced 6. Installation (Manual) 123 / 449 5. Place the drilling template on the spindle. 6. Align the drill template vertically using the printed scale.
Page 124
SmartHandle AX Advanced 6. Installation (Manual) 124 / 449 7. Mark the points to be drilled on the door.
Page 125
SmartHandle AX Advanced 6. Installation (Manual) 125 / 449 8. Remove the drilling template and spindle.
SmartHandle AX Advanced 6. Installation (Manual) 129 / 449 6.4.5 For door thickness X: Preparing the spindle and threaded rods ü Caliper gauge at hand. ü Saw at hand. PH2 screwdriver at hand. ü 1. Measure the door thickness. 2. For door thickness X: screw the 10 mm screws, threaded sleeves and threaded rods together.
SmartHandle AX Advanced 6. Installation (Manual) 130 / 449 4. For X: Use a suitable saw to cut the threaded rods and spindle. 6.4.6 Installing the fitting Door pre-drilled. ü PH2 screwdriver at hand. ü ü TX15 screwdriver at hand.
Page 131
SmartHandle AX Advanced 6. Installation (Manual) 131 / 449 2. For non-MO: screw the blank cylinder firmly into position.
Page 132
SmartHandle AX Advanced 6. Installation (Manual) 132 / 449 3. Insert the sleeve nuts into the fastening plate. 4. For 7 mm spindle: Insert the adapter shoe into the spindle mount on the module support.
Page 133
SmartHandle AX Advanced 6. Installation (Manual) 133 / 449 5. Insert the module support into the fastening plate.
Page 134
SmartHandle AX Advanced 6. Installation (Manual) 134 / 449 6. Slide the module support upwards. Module support snaps into place. 7. Fasten the module support to the fastening plate (PH2) with the 12 mm screws. M5×12...
Page 136
SmartHandle AX Advanced 6. Installation (Manual) 136 / 449 8. Place the compshells on the sleeve nuts.
Page 137
SmartHandle AX Advanced 6. Installation (Manual) 137 / 449 9. Insert the module support with the fastening plate into the outer side of the door. 10. Firmly fasten the cylinder escutcheon to the sleeve nuts (PH2). M4x40 M4x60 M4x80 M4 X...
Page 138
SmartHandle AX Advanced 6. Installation (Manual) 138 / 449 11. For 7 mm spindle: Place the adapter sleeve in the inside handle in such a way that the recess faces the grub screw. 12. Determine the required direction of rotation for your inside handle.
Page 139
SmartHandle AX Advanced 6. Installation (Manual) 139 / 449 14. Pre-tension the spring element on the interchangeable plate. 15. Slide the spring element nose into the slot in the escutcheon.
Page 140
SmartHandle AX Advanced 6. Installation (Manual) 140 / 449 16. Attach the end of the spring element into the slot in the escutcheon. 17. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre of the spindle. Use a punch and hammer to make an indent in the ad-...
Page 141
SmartHandle AX Advanced 6. Installation (Manual) 141 / 449 18. Measure the door thickness. 19. Measure the total length of the spindle. 20.Locate the inside of the spindle (four-edge end up to the centre of the first groove = 26 mm).
Page 143
SmartHandle AX Advanced 6. Installation (Manual) 143 / 449 22. Insert the spindle into the door with the ring-free side as far as it will go. 23. Place the inside handle unit on the spindle. 24.Firmly screw the inside handle unit onto the sleeve nuts (PH2).
Page 144
SmartHandle AX Advanced 6. Installation (Manual) 144 / 449 M4x60 M4x80 M4 X 25. Place the cover on top of the fastening plate.
Page 145
SmartHandle AX Advanced 6. Installation (Manual) 145 / 449 26.Fold down the cover.
Page 146
SmartHandle AX Advanced 6. Installation (Manual) 146 / 449 27. Push the cover against the door, sliding it upwards at the same time. Cover snaps into place.
Page 147
SmartHandle AX Advanced 6. Installation (Manual) 147 / 449 28.Press the inlay into place. 29.Fit the outside handle.
Page 148
SmartHandle AX Advanced 6. Installation (Manual) 148 / 449 30.Use the grub screws to tighten both handles (TX15). 31. Place both rosette covers on their respective rosettes. SmartHandle AX Advanced fully installed.
The active technology, also used in hybrid readers, has a significantly greater range. This can lead to the credential mistakenly communicating with the SmartHandle AX Advanced on the other side of the door. In such cases, activate the close range mode in LSM/AXM (see LSM or ...
SmartHandle AX Advanced 6. Installation (Manual) 151 / 449 6.5.3 Prepare door (drilling template) ü PH2 screwdriver at hand. ü Pin or scriber at hand. Drill at hand. ü Suitable drill bit at hand (Ø 7 mm). ü ü Countersink at hand.
Page 152
SmartHandle AX Advanced 6. Installation (Manual) 152 / 449 2. Place the drilling template on the spindle from the inner side.
Page 153
SmartHandle AX Advanced 6. Installation (Manual) 153 / 449 3. Mark the points to be drilled on the inner side of the door.
Page 156
SmartHandle AX Advanced 6. Installation (Manual) 156 / 449 5. Place the drilling template onto the square from the outside. 6. Align the drill template vertically using the printed scale.
Page 157
SmartHandle AX Advanced 6. Installation (Manual) 157 / 449 7. Mark the points where the door is to be drilled on the door.
SmartHandle AX Advanced 6. Installation (Manual) 163 / 449 6.5.4 For door thickness X: prepare the spindle ü Caliper gauge at hand. ü Saw at hand. 1. Measure the door thickness. 2. For X: mark the sawing point on the spindle.
SmartHandle AX Advanced 6. Installation (Manual) 164 / 449 6.5.5 Installing the fitting ü Door pre-drilled. ü Blind rivet nut pliers at hand. PH2 screwdriver at hand. ü TX15 screwdriver at hand. ü 1. Fit the blind rivet nuts into the pre-drilled holes.
Page 165
SmartHandle AX Advanced 6. Installation (Manual) 165 / 449 2. For non-MO: insert the blank cylinder. NOTE Feed the blank cylinder into the hole using a screwdriver It is difficult to position the blank cylinder correctly, especially in thick doors.
Page 166
SmartHandle AX Advanced 6. Installation (Manual) 166 / 449 3. For non-MO: screw the blank cylinder firmly into position. 4. Use the 12 mm screws to fix the outer fastening plate onto the outer side of the door (PH2) with the tip facing upwards.
Page 168
SmartHandle AX Advanced 6. Installation (Manual) 168 / 449 5. For 7 mm spindle: Insert the adapter shoe into the spindle mount on the module support. 6. Insert the module support into the fastening plate.
Page 169
SmartHandle AX Advanced 6. Installation (Manual) 169 / 449 7. Slide the module support upwards. Module support snaps into place. 8. Use the 18 mm screws to fix the module support onto the fastening plate (PH2). M5×18...
Page 171
SmartHandle AX Advanced 6. Installation (Manual) 171 / 449 9. Place a cover on the fastening plate at the top.
Page 172
SmartHandle AX Advanced 6. Installation (Manual) 172 / 449 10. Fold down the cover.
Page 173
SmartHandle AX Advanced 6. Installation (Manual) 173 / 449 11. Push the cover against the door, sliding it upwards at the same time. Cover snaps into place.
Page 174
SmartHandle AX Advanced 6. Installation (Manual) 174 / 449 12. Press the inlay into place. 13. Fit the outside handle.
Page 175
SmartHandle AX Advanced 6. Installation (Manual) 175 / 449 14. Tighten the grub screw in the outer handle. 15. For 8.5 mm, 9 mm and 10 mm spindle: slide the adapter sleeve into the centre of the spindle. Use a punch and hammer to make an indent in...
Page 176
SmartHandle AX Advanced 6. Installation (Manual) 176 / 449 16. Insert the spindle into the door as far as it will go.
Page 177
SmartHandle AX Advanced 6. Installation (Manual) 177 / 449 17. Use the 12 mm screws to mount the inner fastening plate onto the inner side of the door (PH2) with the tip facing upwards. M5×12...
Page 178
SmartHandle AX Advanced 6. Installation (Manual) 178 / 449 18. For 7 mm spindle: Insert the adapter shoe into the spindle mount on the module support. 19. Use the 18 mm screws to fix the module support onto the fastening plate (PH2).
Page 180
SmartHandle AX Advanced 6. Installation (Manual) 180 / 449 20.Place a cover on the fastening plate at the top.
Page 181
SmartHandle AX Advanced 6. Installation (Manual) 181 / 449 21. Fold down the cover.
Page 182
SmartHandle AX Advanced 6. Installation (Manual) 182 / 449 22. Push the cover against the door, sliding it upwards at the same time. Cover snaps into place.
Page 183
SmartHandle AX Advanced 6. Installation (Manual) 183 / 449 23. Press the inlay into place. 24.Attach an inside handle.
Page 184
SmartHandle AX Advanced 6. Installation (Manual) 184 / 449 25. Fasten the grub screw into the inside handle. SmartHandle AX Advanced fully installed.
1. Do not press on the screws when fastening the module support into place. 2. Place a finger on the ends of the threaded sleeves to hold them in place while screwing. 6.6.2 Scope of delivery SmartHandle AX Advanced Security fitting Special tool Quick guide ...
SmartHandle AX Advanced 6. Installation (Manual) 187 / 449 6.6.4 Prepare door (drilling template) ü Pin or scriber at hand. ü Drill at hand. Suitable drill available (Ø 13 mm). ü PH2 screwdriver at hand. ü 1. Insert the spindle into the mortise lock.
Page 188
SmartHandle AX Advanced 6. Installation (Manual) 188 / 449 2. Place the drilling template on the spindle. 3. Align the drill template vertically using the printed scale.
Page 189
SmartHandle AX Advanced 6. Installation (Manual) 189 / 449 4. Mark the drill holes with mark 1.
Page 190
SmartHandle AX Advanced 6. Installation (Manual) 190 / 449 5. Remove the drilling template and rotate it 180 degrees.
Page 191
SmartHandle AX Advanced 6. Installation (Manual) 191 / 449 6. Place the drilling template on the spindle. 7. Align the drill template vertically using the printed scale.
Page 192
SmartHandle AX Advanced 6. Installation (Manual) 192 / 449 8. Mark the drill hole with mark 2.
Page 193
SmartHandle AX Advanced 6. Installation (Manual) 193 / 449 9. Remove the drilling template and spindle.
SmartHandle AX Advanced 6. Installation (Manual) 198 / 449 6.6.5 Installing the fitting ü Door pre-drilled. ü PH2 screwdriver at hand. TX15 screwdriver at hand. ü Have an SW6 hex slotted-head screwdriver ready. ü ü Have an SW5 hex slotted-head screwdriver ready.
Page 199
SmartHandle AX Advanced 6. Installation (Manual) 199 / 449 3. Insert the module support into the fastening plate. IMPORTANT Damage to the sleeve nuts due to improper insertion If the sleeve nut tabs are not located in the recesses, they can be damaged during further installation.
Page 200
SmartHandle AX Advanced 6. Installation (Manual) 200 / 449 4. Slide the module support upwards. Module support snaps into place.
Page 201
SmartHandle AX Advanced 6. Installation (Manual) 201 / 449 5. Fasten the module support to the fixing plate (PH2) with the 16 mm screws. M5×16...
Page 202
SmartHandle AX Advanced 6. Installation (Manual) 202 / 449 6. Measure the door thickness.
Page 205
SmartHandle AX Advanced 6. Installation (Manual) 205 / 449 8. Insert the module support with the fastening plate and the drill protec- tion plate into the outer side of the door. IMPORTANT Damage to the sleeve nuts due to improper insertion If the sleeve nut tabs are not located in the recesses, they can be damaged during further installation.
Page 206
SmartHandle AX Advanced 6. Installation (Manual) 206 / 449 9. Screw the washers and the inner plate firmly onto the module support (SW6 short screws, SW5 long screw in the centre). 10. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre of the spindle.
Page 207
SmartHandle AX Advanced 6. Installation (Manual) 207 / 449 11. Measure the total length of the spindle. 12. Locate the inside of the spindle (four-edge end up to the centre of the first groove = 26 mm). 13. Use the table to determine the position of the O-ring.
Page 209
SmartHandle AX Advanced 6. Installation (Manual) 209 / 449 15. Insert the spindle into the door with the ring-free side as far as it will go. 16. Insert the filling profile onto the inner fixing plate.
Page 210
SmartHandle AX Advanced 6. Installation (Manual) 210 / 449 17. For 7 mm spindle: Place the adapter sleeve in the inside handle in such a way that the recess faces the grub screw. 18. Determine the required direction of rotation for your inside handle.
Page 211
SmartHandle AX Advanced 6. Installation (Manual) 211 / 449 20.Place the inside handle unit on the spindle. 21. Use the 12 mm screws to fasten the inner handle unit onto the fixing plate (PH2). M5×12...
Page 212
SmartHandle AX Advanced 6. Installation (Manual) 212 / 449 22. Place the cover on top of the fastening plate.
Page 213
SmartHandle AX Advanced 6. Installation (Manual) 213 / 449 23. Fold down the cover.
Page 215
SmartHandle AX Advanced 6. Installation (Manual) 215 / 449 25. Press the inlay into place. 26.Fit the outside handle.
Page 216
SmartHandle AX Advanced 6. Installation (Manual) 216 / 449 27. Use the grub screw to fasten the outer handle (TX15) into position. 28.Use the grub screw to fasten the inner handle (TX15) into position.
Page 217
30.Insert a locking cylinder. NOTE Requirements for the security fitting approval The approval for the SmartHandle AX Advanced is subject to conditions: 1. Observe the locking cylinder’s protection class. 2. The locking cylinder’s housing may protrude a maximum of 3 mm above...
SmartHandle AX Advanced 6. Installation (Manual) 221 / 449 6.7.4 Prepare door (drilling template) ü Pin or scriber at hand. ü Drill at hand. Suitable drill bit at hand (Ø 7 mm). ü PH2 screwdriver at hand. ü ü For PO (oval escutcheon): Countersink at hand.
Page 222
SmartHandle AX Advanced 6. Installation (Manual) 222 / 449 2. Measure the distance (gap between the spindle and cylinder axes of ro- tation).
Page 223
SmartHandle AX Advanced 6. Installation (Manual) 223 / 449 3. Fit the mortise lock.
Page 224
SmartHandle AX Advanced 6. Installation (Manual) 224 / 449 4. Insert the spindle into the mortise lock.
Page 225
SmartHandle AX Advanced 6. Installation (Manual) 225 / 449 5. Place the drilling template on the spindle. 6. Align the drill template vertically using the printed scale.
Page 226
SmartHandle AX Advanced 6. Installation (Manual) 226 / 449 7. Mark the points to be drilled on the door.
Page 227
SmartHandle AX Advanced 6. Installation (Manual) 227 / 449 8. Remove the drilling template and spindle.
Page 231
SmartHandle AX Advanced 6. Installation (Manual) 231 / 449 11. For PO (oval escutcheon): Countersink the holes with a countersink so that you can then insert the blind rivet nuts into a flush position. 12. For PO (oval escutcheon): Insert a blind rivet nut on the outer side as...
Page 232
SmartHandle AX Advanced 6. Installation (Manual) 232 / 449 13. For PO (oval escutcheon): Insert the blind rivet nuts on the inner side.
SmartHandle AX Advanced 6. Installation (Manual) 233 / 449 14. Fit the mortise lock. 6.7.5 Installing the fitting Door pre-drilled. ü ü PH2 screwdriver at hand. TX15 screwdriver at hand. ü Caliper gauge at hand. ü ü Saw at hand.
Page 234
SmartHandle AX Advanced 6. Installation (Manual) 234 / 449 2. Measure the door thickness and determine the length of the spindle. *PS* (with backplate) *PO* (with oval escutcheon) Door thickness – Door thickness + BKS (bar handle) BKS (bar handle) 27.8 ± 1.5 27.8 ±1.5 mm...
Page 235
SmartHandle AX Advanced 6. Installation (Manual) 235 / 449 3. Trim the spindle with a suitable saw. 4. Obtain the screws not included in the scope of delivery from the manu- facturer of your panic bar. NOTE Panic bar manufacturer’s specifications The panic bar manufacturer may impose further requirements on the screws, including strength and length.
Page 236
SmartHandle AX Advanced 6. Installation (Manual) 236 / 449 Door thickness – 10 ± 5 mm See panic bar manufacturer documentation...
Page 237
SmartHandle AX Advanced 6. Installation (Manual) 237 / 449 5. Insert the sleeve nuts and spindle protection into the fixing plate.
Page 239
SmartHandle AX Advanced 6. Installation (Manual) 239 / 449 6. Insert a spacer ring into the hole in the middle sleeve nut.
Page 240
SmartHandle AX Advanced 6. Installation (Manual) 240 / 449 7. Insert the module support into the fastening plate.
Page 241
SmartHandle AX Advanced 6. Installation (Manual) 241 / 449 8. Slide the module support upwards. Module support snaps into place. 9. Fasten the module support to the fixing plate (PH2) with the 16 mm screws. M5×16...
Page 243
SmartHandle AX Advanced 6. Installation (Manual) 243 / 449 10. Insert the spindle into the fitting.
Page 244
SmartHandle AX Advanced 6. Installation (Manual) 244 / 449 11. Insert the module support with the fastening plate into the outer side of the door.
Page 246
SmartHandle AX Advanced 6. Installation (Manual) 246 / 449 12. For non-MO: insert the blank cylinder. 13. For non-MO: screw the blank cylinder firmly into position. 14. For PO (oval escutcheon): Screw on the oval escutcheon base (PH2).
Page 247
SmartHandle AX Advanced 6. Installation (Manual) 247 / 449 15. For PO (oval escutcheon): Place the covers on the oval escutcheon base. 16. Screw on the panic bar mounting plate (TX25, PO [oval escutcheon] and PH2).
Page 248
SmartHandle AX Advanced 6. Installation (Manual) 248 / 449 17. Observe any manufacturer-specific requirements for attaching the mounting plate.
Page 249
SmartHandle AX Advanced 6. Installation (Manual) 249 / 449 18. Fasten the panic bar according to the manufacturer’s specifications (e.g. using grub screw). 19. Place the cover on top of the fastening plate.
Page 250
SmartHandle AX Advanced 6. Installation (Manual) 250 / 449 20.Fold down the cover.
SmartHandle AX Advanced 6. Installation (Manual) 254 / 449 Panic bar Screws for fastening the panic bar itself 6.8.2 Structure with backplate (*PS*)
SmartHandle AX Advanced 6. Installation (Manual) 256 / 449 6.8.4 Prepare door (drilling template) ü Pin or scriber at hand. ü Drill at hand. Have suitable drill bit at hand (Ø 7 mm; also Ø 6 mm to install round ü escutcheon). PH2 screwdriver at hand.
Page 257
SmartHandle AX Advanced 6. Installation (Manual) 257 / 449 2. Measure the distance (gap between the spindle and cylinder axes of ro- tation).
Page 258
SmartHandle AX Advanced 6. Installation (Manual) 258 / 449 3. Fit the mortise lock.
Page 259
SmartHandle AX Advanced 6. Installation (Manual) 259 / 449 4. Insert the spindle into the mortise lock.
Page 260
SmartHandle AX Advanced 6. Installation (Manual) 260 / 449 5. Place the drilling template on the spindle. 6. Align the drill template vertically using the printed scale.
Page 261
SmartHandle AX Advanced 6. Installation (Manual) 261 / 449 7. Mark the points to be drilled on the door.
SmartHandle AX Advanced 6. Installation (Manual) 268 / 449 11. Fit the mortise lock. 6.8.5 Installing the fitting Door pre-drilled. ü ü PH2 screwdriver at hand. TX15 screwdriver at hand. ü Caliper gauge at hand. ü ü Saw at hand.
Page 269
SmartHandle AX Advanced 6. Installation (Manual) 269 / 449 2. Measure the door thickness and determine the length of the spindle. *PS* (with backplate) *PO* (with round escutcheon) Door thickness – BKS (bar handle) 27.8 ± 1.5 mm Door thickness – BKS (push bar) 36.8 ±...
Page 270
SmartHandle AX Advanced 6. Installation (Manual) 270 / 449 3. Trim the spindle with a suitable saw. 4. Obtain the screws not included in the scope of delivery from the manu- facturer of your panic bar. NOTE Panic bar manufacturer’s specifications The panic bar manufacturer may impose further requirements on the screws, including strength and length.
Page 271
SmartHandle AX Advanced 6. Installation (Manual) 271 / 449 Door thickness – 10 ± 5 mm) See panic bar manufacturer documentation...
Page 272
SmartHandle AX Advanced 6. Installation (Manual) 272 / 449 5. Insert the sleeve nuts and spindle protection into the fixing plate.
Page 276
SmartHandle AX Advanced 6. Installation (Manual) 276 / 449 7. Insert the module support into the fastening plate.
Page 277
SmartHandle AX Advanced 6. Installation (Manual) 277 / 449 8. Slide the module support upwards. Module support snaps into place. 9. Fasten the module support to the fixing plate (PH2) with the 16 mm screws. M5×16...
Page 279
SmartHandle AX Advanced 6. Installation (Manual) 279 / 449 10. Insert the spindle into the fitting.
Page 280
SmartHandle AX Advanced 6. Installation (Manual) 280 / 449 11. Insert the module support with the fastening plate into the outer side of the door. 12. For non-MO: insert the blank cylinder.
Page 281
SmartHandle AX Advanced 6. Installation (Manual) 281 / 449 13. For non-MO: screw the blank cylinder firmly into position. 14. For PO (round escutcheon): Fasten the round escutcheon base firmly (PH2). M4x40 M4x60 M4x80 M4 X...
Page 282
SmartHandle AX Advanced 6. Installation (Manual) 282 / 449 15. For PO (round escutcheon): Place the cover on the round escutcheon base. 16. Fasten the panic bar mounting plate firmly (TX25).
Page 283
SmartHandle AX Advanced 6. Installation (Manual) 283 / 449 17. Observe any manufacturer-specific requirements for attaching the mounting plate. 18. Fasten the panic bar according to the manufacturer’s specifications (e.g. using grub screw).
Page 284
SmartHandle AX Advanced 6. Installation (Manual) 284 / 449 19. Place the cover on top of the fastening plate.
Page 285
SmartHandle AX Advanced 6. Installation (Manual) 285 / 449 20.Fold down the cover.
6.9.3 Prepare door (drilling template) NOTE Fastening in the centre is optional Fastening in the centre is optional. The SmartHandle AX Advanced can also be installed without this fastening system. Use the middle fastener if you require greater stability. ...
Page 291
SmartHandle AX Advanced 6. Installation (Manual) 291 / 449 ü Pin or scriber at hand. Drill at hand. ü Suitable drill bit at hand (Ø 7 mm). ü ü PH2 screwdriver at hand. 1. Insert the spindle into the mortise lock.
Page 292
SmartHandle AX Advanced 6. Installation (Manual) 292 / 449 2. Place the drilling template on the spindle. 3. Align the drill template vertically using the printed scale.
Page 293
SmartHandle AX Advanced 6. Installation (Manual) 293 / 449 4. Mark the drill holes with mark 1.
Page 294
SmartHandle AX Advanced 6. Installation (Manual) 294 / 449 5. Remove the drilling template and rotate it 180 degrees.
Page 296
SmartHandle AX Advanced 6. Installation (Manual) 296 / 449 6. Place the drilling template on the spindle. 7. Align the drill template vertically using the printed scale.
Page 297
SmartHandle AX Advanced 6. Installation (Manual) 297 / 449 8. Mark the drill hole with mark 2.
Page 298
SmartHandle AX Advanced 6. Installation (Manual) 298 / 449 9. Remove the drilling template and spindle.
SmartHandle AX Advanced 6. Installation (Manual) 303 / 449 6.9.4 For door thickness X: have the threaded rods and spindle ready at hand ü Caliper gauge at hand. ü Saw at hand. PH2 screwdriver at hand. ü 1. Measure the door thickness.
4. For X: Use a suitable saw to cut the threaded rods and spindle. 6.9.5 Installing the fitting NOTE Fastening in the centre is optional Fastening in the centre is optional. The SmartHandle AX Advanced can also be installed without this fastening system. Use the middle fastener if you require greater stability. ...
Page 305
SmartHandle AX Advanced 6. Installation (Manual) 305 / 449 ü Door pre-drilled. PH2 screwdriver at hand. ü TX15 screwdriver at hand. ü ü Caliper gauge at hand. 1. Insert the spindle protective tube and the sleeve nuts into the fastening...
Page 306
SmartHandle AX Advanced 6. Installation (Manual) 306 / 449 2. Insert a spacer ring into the openings in the middle and top sleeve nuts. 3. For 7 mm spindle: Insert the adapter shoe into the spindle mount on the module support.
Page 307
SmartHandle AX Advanced 6. Installation (Manual) 307 / 449 4. Insert the module support into the fastening plate.
Page 308
SmartHandle AX Advanced 6. Installation (Manual) 308 / 449 5. Slide the module support upwards. Module support snaps into place. 6. Fasten the module support to the fastening plate (PH2) with the 12 mm screws. M5×12...
Page 309
SmartHandle AX Advanced 6. Installation (Manual) 309 / 449 7. For non-MO: insert the blank cylinder. NOTE Feed the blank cylinder into the hole using a screwdriver It is difficult to position the blank cylinder correctly, especially in thick doors.
Page 310
SmartHandle AX Advanced 6. Installation (Manual) 310 / 449 8. For non-MO: screw the blank cylinder firmly into position.
Page 312
SmartHandle AX Advanced 6. Installation (Manual) 312 / 449 11. Insert the module support with the fastening plate into the outer side of the door. 12. For X: Insert the screws through the inner fastening plate and screw them together with the threaded sleeve and threaded rod.
Page 313
SmartHandle AX Advanced 6. Installation (Manual) 313 / 449 13. Screw the inner fixing plate to the outer part (PH2) with the required screws. M5×35 M5×45 M5×50 M5×60 M5×70 M5×80...
Page 314
SmartHandle AX Advanced 6. Installation (Manual) 314 / 449 14. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre of the spindle. Use a punch and hammer to make an indent in the ad- apter sleeve to prevent it from slipping.
Page 315
SmartHandle AX Advanced 6. Installation (Manual) 315 / 449 15. Measure the total length of the spindle. 16. Locate the inside of the spindle (four-edge end up to the centre of the first groove = 26 mm). 17. Use the table to determine the position of the O-ring.
Page 317
SmartHandle AX Advanced 6. Installation (Manual) 317 / 449 18. Slide the O-ring onto the calculated groove. 19. Insert the spindle into the door with the ring-free side as far as it will go.
Page 318
SmartHandle AX Advanced 6. Installation (Manual) 318 / 449 20.Insert the filling profile onto the inner fixing plate. 21. For 7 mm spindle: Place the adapter sleeve in the inside handle in such a way that the recess faces the grub screw.
Page 319
SmartHandle AX Advanced 6. Installation (Manual) 319 / 449 23. Insert the spring element appropriately. 24.Place the inside handle unit on the spindle. 25. Use the 12 mm screws to fasten the inner handle unit onto the fixing plate (PH2). M5×12...
Page 320
SmartHandle AX Advanced 6. Installation (Manual) 320 / 449 26.Place the cover on top of the fastening plate.
Page 321
SmartHandle AX Advanced 6. Installation (Manual) 321 / 449 27. Fold down the cover.
SmartHandle AX Advanced 6. Installation (Manual) 327 / 449 6.10.3 Prepare door (drilling template) ü Pin or scriber at hand. ü Drill at hand. Suitable drill bit at hand (Ø 7 mm). ü PH2 screwdriver at hand. ü 1. Insert the spindle into the mortise lock.
Page 328
SmartHandle AX Advanced 6. Installation (Manual) 328 / 449 2. Place the drilling template on the spindle. 3. Align the drill template vertically using the printed scale.
Page 329
SmartHandle AX Advanced 6. Installation (Manual) 329 / 449 4. Mark the drill holes with mark 1.
Page 330
SmartHandle AX Advanced 6. Installation (Manual) 330 / 449 5. Remove the drilling template and rotate it 180 degrees.
Page 332
SmartHandle AX Advanced 6. Installation (Manual) 332 / 449 6. Place the drilling template on the spindle. 7. Align the drill template vertically using the printed scale.
Page 333
SmartHandle AX Advanced 6. Installation (Manual) 333 / 449 8. Mark the drill hole with mark 2.
Page 334
SmartHandle AX Advanced 6. Installation (Manual) 334 / 449 9. Remove the drilling template and spindle.
SmartHandle AX Advanced 6. Installation (Manual) 339 / 449 6.10.4 For door thickness X: have the threaded rods and spindle ready at hand ü Caliper gauge at hand. ü Saw at hand. PH2 screwdriver at hand. ü 1. Measure the door thickness.
SmartHandle AX Advanced 6. Installation (Manual) 340 / 449 4. For X: Use a suitable saw to cut the threaded rods and spindle. 6.10.5 Installing the fitting ü Door pre-drilled. PH2 screwdriver at hand. ü ü TX15 screwdriver at hand.
Page 341
SmartHandle AX Advanced 6. Installation (Manual) 341 / 449 2. For non-MO: screw the blank cylinder firmly into position.
Page 342
SmartHandle AX Advanced 6. Installation (Manual) 342 / 449 3. Insert the spindle protection tube into the fixing plate. 4. For 7 mm spindle: Insert the adapter shoe into the spindle mount on the module support.
Page 343
SmartHandle AX Advanced 6. Installation (Manual) 343 / 449 5. Insert the module support into the fastening plate.
Page 344
SmartHandle AX Advanced 6. Installation (Manual) 344 / 449 6. Slide the module support upwards. Module support snaps into place. 7. Screw the threaded sleeves onto the fixing plate threaded bolts. 8. Fasten the module support to the fastening plate (PH2) with the 12 mm screws.
Page 345
SmartHandle AX Advanced 6. Installation (Manual) 345 / 449 9. Insert the module support with the fastening plate into the outer side of the door. NOTE Reducing sleeves for existing 14 mm holes Existing 14 mm holes make it difficult to secure the SmartHandle AX Ad- vanced.
Page 346
SmartHandle AX Advanced 6. Installation (Manual) 346 / 449 10. For 7 mm spindle: Place the adapter sleeve in the inside handle in such a way that the recess faces the grub screw. 11. Determine the required direction of rotation for your inside handle.
Page 347
SmartHandle AX Advanced 6. Installation (Manual) 347 / 449 13. Place the underlay in the inner handle unit. 14. Screw the inside handle together with the threaded sleeves and 10 mm screws onto the fixing plate (2.5 mm hex key and PH2).
Page 348
SmartHandle AX Advanced 6. Installation (Manual) 348 / 449 15. For 8.5 mm and 10 mm spindle: slide the adapter sleeve into the centre of the spindle. Use a punch and hammer to make an indent in the ad- apter sleeve to prevent it from slipping.
Page 349
SmartHandle AX Advanced 6. Installation (Manual) 349 / 449 18. Use the table to determine the position of the O-ring. Door thickness Spindle length Size Ring position (mm) (mm) 38 – <41 38 – <41 41 – <46 41 – <46 46 –...
Page 350
SmartHandle AX Advanced 6. Installation (Manual) 350 / 449 19. Slide the O-ring onto the calculated groove. 20.Insert the spindle into the door with the ring-free side as far as it will go.
Page 352
SmartHandle AX Advanced 6. Installation (Manual) 352 / 449 24.Screw the inner part and the outer part (PH2) with the required screws. NOTE Reducing sleeves for existing 14 mm holes Existing 14 mm holes make it difficult to secure the SmartHandle AX Ad- vanced.
Page 354
SmartHandle AX Advanced 6. Installation (Manual) 354 / 449 26.Place a cover with the notch facing downwards onto the escutcheon base. 27. Place the cover on top of the fastening plate.
Page 355
SmartHandle AX Advanced 6. Installation (Manual) 355 / 449 28.Fold down the cover.
SmartHandle AX Advanced 7. Removing the fitting (Manual) 359 / 449 7. Removing the fitting Always carry out disassembly using the same steps as installation but in reverse order. In addition to the grub screw, the outside handle is also secured by a security pin in the spindle.
Page 360
SmartHandle AX Advanced 7. Removing the fitting (Manual) 360 / 449 7.1 Removing the fitting (metal frame) ü 1.5 mm hexagonal wrench available. 1. Insert a flat-head screwdriver (ideally angled) into the opening in the lower surface of the panels on the inside.
5. Insert a 1.5 mm hex key into the hole in the spindle mount in the module support. 6. Bend the hex key to the side where the hole is located while pulling on the outside handle. SmartHandle AX Advanced is now removed. 7.2 Removing the fitting (long backplate/short backplate) 1.5 mm hexagonal wrench available. ü...
Page 362
3. Insert a 1.5 mm hex key into the hole in the spindle mount in the module support. 4. Bend the hex key to the side where the hole is located while pulling on the outside handle. SmartHandle AX Advanced is now removed.
SmartHandle AX Advanced 7. Removing the fitting (Manual) 363 / 449 7.3 Removing the fitting (Scandinavian Oval) ü 1.5 mm hexagonal wrench available. 1. Remove the fitting in the reverse order to installation. 2. Loosen the cover by bending the inlay outwards using the special tool.
364 / 449 4. Bend the hex key to the side where the hole is located while pulling on the outside handle. SmartHandle AX Advanced is now removed. 7.4 Removing the fitting (full leaf) ü 1.5 mm hexagonal wrench available.
4. Bend the hex key to the side where the hole is located while pulling on the outside handle. SmartHandle AX Advanced is now removed. 7.5 Removing the fitting (reading on both sides) 1.5 mm hexagonal wrench available. ü...
Page 366
3. Insert a 1.5 mm hex key into the hole in the spindle mount in the module support. 4. Bend the hex key to the side where the hole is located while pulling on the outside handle. SmartHandle AX Advanced is now removed.
3. Insert a 1.5 mm hex key into the hole in the spindle mount in the module support. 4. Bend the hex key to the side where the hole is located while pulling on the outside handle. SmartHandle AX Advanced is now removed.
3. Insert a 1.5 mm hex key into the hole in the spindle mount in the module support. 4. Bend the hex key to the side where the hole is located while pulling on the outside handle. SmartHandle AX Advanced is now removed.
SmartHandle AX Advanced 9. Configuration (Manual) 370 / 449 9. Configuration The configuration of the SmartHandle AX Advanced is changed with the AXM/LSM.
SmartHandle AX Advanced 10. Operation (Manual) 371 / 449 10. Operation The SmartHandle AX can be operated in different ways, depending on the programming. NOTE The size of the gap affects the wireless connection. 1. If you use a transponder, you must position it between five and thirty centimetres away.
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 372 / 449 11. Accessories and spare parts 11.1 LockNode Item code Description LockNode for retrofitting of WNM.LN.I.S3 SmartHandle AX Advanced 11.1.1 Intended use 11.1.2 Fitting the LockNode ü Special tool at hand.
Page 373
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 373 / 449 2. Use the special tool to carefully bend the cover inlay upwards. 3. Slide the cover downwards. Cover unlocked.
Page 374
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 374 / 449 4. Remove the cover. 5. Use the special tool to unhook the reader module clip.
Page 375
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 375 / 449 6. Remove the reader module.
Page 376
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 376 / 449 7. Push the LockNode into its designated slot.
Page 377
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 377 / 449 8. Place the reader module back into the module support.
Page 378
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 378 / 449 SmartHandle AX Advanced will beep three times. 9. Use the special tool to reattach the reader module clip. 10. Place the cover on top of the fastening plate.
Page 379
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 379 / 449 11. Fold down the cover. 12. Push the cover against the door, sliding it upwards at the same time. Cover snaps into place. 13. Press the inlay into place.
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 380 / 449 11.1.3 Fitting the LockNode (Scandinavian Oval) ü Special tool at hand. 1. Insert the special tool into the cover inlay on the electronics side. 2. Use the special tool to carefully bend the cover inlay upwards.
Page 381
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 381 / 449 3. Slide the cover upwards. Cover unlocked. 4. Remove the cover.
Page 382
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 382 / 449 5. Use the special tool to unhook the reader module clip. 6. Remove the reader module.
Page 383
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 383 / 449 7. Push the LockNode into its designated slot. 8. Place the reader module back into the module support.
Page 384
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 384 / 449 SmartHandle AX Advanced will beep three times. 9. Use the special tool to reattach the reader module clip.
Page 385
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 385 / 449 10. Position the cover on the fastening plate at the bottom. 11. Fold the cover upwards.
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 386 / 449 12. Push the cover against the door while sliding it downwards at the same time. Cover snaps into place. 13. Press the inlay into place. LockNode is mounted.
Page 387
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 387 / 449 Item code Description Handle inside and outside with round rosette for S3.LEVER.RR.X.Y retrofitting for: L1 (Mounting of rosettes) Inner side and outer side handle for retrofitting of: N1 (Long ...
Page 388
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 388 / 449 Handle variants Letter Description L-shaped R (round, curved) L-shaped G (mitred) В U-shaped R (round curved) U-shaped G (mitred) U-shaped, rounded, offset U-shape (rectangular and offset)
Page 389
Third-party handle adapter (FSB) third-party handles, see 391] Spindle This is SmartHandle AX Advanced available for various spindle sockets in the mortise lock (see also Spindle socket in mortise lock [ 22] You SmartHandle AX Advanced have one of three spindles: 7 mm...
Page 390
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 390 / 449 To order the correct handle set, all you need to know is the width of the spindle. You can easily measure these. 1. Remove the inside handle. 2. For 7 mm spindle only: pull the adapter off the spindle.
SmartHandle AX Advanced 11. Accessories and spare parts (Manual) 391 / 449 11.3 Third-party handle adapter (FSB) Item code Description Adapter set for FSB lever handles from FSB model year 2018, compatible with S2.AD- the following FSB fastening APTER.FSB types: Standard (FSB ASL®)
SmartHandle AX Advanced 12. Signal (Manual) 393 / 449 12. Signal Signal Meaning 2x short before engaging to open Identification medium accepted – (green) normal activation Identification medium not author- 1 x short (red) ised Flip-flop mode: Locking device is 1×...
SmartHandle AX Advanced 13. Battery management (Manual) 394 / 449 13. Battery management 13.1 Battery warning 13.1.1 Warning level warning level Signalling Meaning 8 x short bleep/flash Batteries are nearly Warning Level 1 before engagement dead and must be (red) changed.
Page 395
SmartHandle AX Advanced 13. Battery management (Manual) 395 / 449 2. Use the special tool to carefully bend the cover inlay upwards. 3. Slide the cover downwards. Cover unlocked.
Page 396
SmartHandle AX Advanced 13. Battery management (Manual) 396 / 449 4. Remove the cover. 5. Use the special tool to detach the battery module clip.
Page 397
SmartHandle AX Advanced 13. Battery management (Manual) 397 / 449 6. Remove the battery module. 7. Use the special tool to detach the battery clip. 8. Remove the upper batteries.
Page 398
SmartHandle AX Advanced 13. Battery management (Manual) 398 / 449 9. Carefully bend the intermediate spring to one side. 10. Remove the lower batteries. 11. Insert two new batteries with the positive terminals next to each other (type CR2450). Intermediate spring visible above the lower batteries.
Page 399
SmartHandle AX Advanced 13. Battery management (Manual) 399 / 449 12. Insert two new batteries with the positive terminals next to each other (type CR2450). 13. Reattach the battery clip.
Page 400
SmartHandle AX Advanced 13. Battery management (Manual) 400 / 449 14. Put the battery module back into the module support. 15. Use the special tool to reattach the battery module clip. SmartHandle AX Advanced will beep three times.
Page 401
SmartHandle AX Advanced 13. Battery management (Manual) 401 / 449 16. Place the cover on top of the fastening plate. 17. Fold down the cover.
Page 402
SmartHandle AX Advanced 13. Battery management (Manual) 402 / 449 18. Push the cover against the door, sliding it upwards at the same time. Cover snaps into place. 19. Press the inlay into place. Batteries are now replaced.
SmartHandle AX Advanced 13. Battery management (Manual) 403 / 449 13.3 Replacing batteries (Scandinavian Oval) NOTE Malfunctions due to poor contact or different discharge Contact surfaces that are too small/contaminated or different discharged batteries can lead to malfunctions. 1. Only use batteries that are approved by SimonsVoss.
Page 404
SmartHandle AX Advanced 13. Battery management (Manual) 404 / 449 2. Use the special tool to carefully bend the cover inlay upwards. 3. Slide the cover upwards. Cover unlocked.
Page 405
SmartHandle AX Advanced 13. Battery management (Manual) 405 / 449 4. Remove the cover. 5. Use the special tool to detach the battery module clip.
Page 406
SmartHandle AX Advanced 13. Battery management (Manual) 406 / 449 6. Remove the battery module. 7. Use the special tool to detach the battery clip.
Page 407
SmartHandle AX Advanced 13. Battery management (Manual) 407 / 449 8. Remove the upper batteries. 9. Carefully bend the intermediate spring to one side. 10. Remove the lower batteries.
Page 408
SmartHandle AX Advanced 13. Battery management (Manual) 408 / 449 11. Insert two new batteries with the positive terminals next to each other (type CR2450). Intermediate spring visible above the lower batteries.
Page 409
SmartHandle AX Advanced 13. Battery management (Manual) 409 / 449 12. Insert two new batteries with the positive terminals next to each other (type CR2450). 13. Reattach the battery clip.
Page 410
SmartHandle AX Advanced 13. Battery management (Manual) 410 / 449 14. Put the battery module back into the module support.
Page 411
SmartHandle AX Advanced 13. Battery management (Manual) 411 / 449 15. Use the special tool to reattach the battery module clip. SmartHandle AX Advanced will beep three times. 16. Position the cover on the fastening plate at the bottom.
Page 412
SmartHandle AX Advanced 13. Battery management (Manual) 412 / 449 17. Fold the cover upwards. 18. Push the cover against the door while sliding it downwards at the same time. Cover snaps into place.
Page 413
SmartHandle AX Advanced 13. Battery management (Manual) 413 / 449 19. Press the inlay into place. Batteries are now replaced.
14. Maintenance, cleaning and disinfec- SmartHandle AX Advanced tion (Manual) 414 / 449 14. Maintenance, cleaning and disinfection If necessary, clean the SmartHandle AX with a soft and, if necessary, damp cloth. When disinfecting the SmartHandle AX, only use agents that are ...
SmartHandle AX Advanced 15. Technical data (Manual) 415 / 449 15. Technical data Electronics Operating temperature range -25 °C to +60 °C Battery type 4x CR2450 3V lithium Duracell Battery manufacturer Murata Panasonic Up to ten years on stand-by (active...
Page 416
SmartHandle AX Advanced 15. Technical data (Manual) 416 / 449 Mechanical system Metal frame doors (oval escutcheons) Solid-leaf doors Euro Profile cylinders, Swiss Installation variants Round (round escutcheons, long backplate, short backplate, security fitting) Scandinavian Oval ...
Page 417
SmartHandle AX Advanced 15. Technical data (Manual) 417 / 449 7 mm 8 mm Spindle 8.5 mm 9 mm 10 mm IP protection rating Up to IP66 (WP variant) Stainless steel/dark grey (RAL 7021)
Page 418
SmartHandle AX Advanced 15. Technical data (Manual) 418 / 449 Emissions Radio emissions 15.24 kHz - 72.03 kHz 10 dBµA/m (3 m distance) Only for item numbers: SV- S3.*AM.G2*, SV-S3.*A.G2* 13.560006 MHz - 13.560780 MHz 1.04 dBµA/m (3 m distance) Only for item numbers: SV- S3.*AM.G2*, SV-S3.*A.G2*...
SmartHandle AX Advanced 15. Technical data (Manual) 419 / 449 15.1 Scale drawings 15.1.1 fittings 15.1.1.1 Long backplate/short backplate Inner side Outer side Door thickness...
Page 420
SmartHandle AX Advanced 15. Technical data (Manual) 420 / 449 15.1.1.2 Metal frame Outer side Inner side Door thickness...
Page 421
SmartHandle AX Advanced 15. Technical data (Manual) 421 / 449 15.1.1.3 Scandinavian Oval Door thickness Outer side Inner side...
Page 422
SmartHandle AX Advanced 15. Technical data (Manual) 422 / 449 15.1.1.4 Escutcheon installation Outside Inside Door thickness...
Page 423
SmartHandle AX Advanced 15. Technical data (Manual) 423 / 449 15.1.1.5 Reader on both sides Inside Outside Door thickness...
Page 424
SmartHandle AX Advanced 15. Technical data (Manual) 424 / 449 15.1.1.6 Security fitting Inside Outside Door thickness...
Page 425
SmartHandle AX Advanced 15. Technical data (Manual) 425 / 449 15.1.1.7 Panic fitting with narrow backplate With backplate Inside Outside Door thickness...
Page 426
SmartHandle AX Advanced 15. Technical data (Manual) 426 / 449 With oval escutcheon Inside Outside Door thickness...
Page 427
SmartHandle AX Advanced 15. Technical data (Manual) 427 / 449 15.1.1.8 Panic fitting with wide backplate With backplate Inside Outside Door thickness...
Page 428
SmartHandle AX Advanced 15. Technical data (Manual) 428 / 449 With round escutcheon Inside Outside Door thickness...
Page 429
SmartHandle AX Advanced 15. Technical data (Manual) 429 / 449 15.1.1.9 Conventional installation SH3062/FR195 Inside Outside Door thickness...
Page 430
SmartHandle AX Advanced 15. Technical data (Manual) 430 / 449 15.1.1.10 Conventional installation 105/145 Inside Outside Door thickness...
SmartHandle AX Advanced 16. Declaration of conformity (Manual) 447 / 449 16. Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that the articles (SV-S3.*M.G2*, SV-S3.*AM.G2*, SV-S3.*A.G2*) comply with the following guidelines: ...
SmartHandle AX Advanced 17. Help and other information (Manual) 448 / 449 17. Help and other information Information material/documents You will find detailed information on operation and configuration and other documents on the website: https://www.simons-voss.com/en/documents.html Information on disposal Do not dispose the device (SV-S3.*M.G2*, SV-S3.*AM.G2*, SV- ...
Page 449
This is SimonsVoss SimonsVoss, the pioneer in remote-controlled, cable-free locking technology provides system solutions with a wide range of products for SOHOs, SMEs, major companies and public institutions. SimonsVoss locking systems combine intelligent functionality, high quality and award- winning design Made in Germany. As an innovative system provider, SimonsVoss focuses on scalable systems, high security, reliable components, powerful software and simple operation.
