GUIDE TO INSTALLATION
The following can be used as a checklist to verify all of the steps necessary
for complete installation of the C-BOX 200.
1) Read all information in the section "Safety Precautions" at the beginning
of this manual.
2) Correctly position and mount the C-BOX 200 within the reach of the
barcode scanner cable, according to the information in paragraph 2.3.
3) Provide correct system cabling according to the signals necessary for
your application and RS485 settings (see all sub-paragraphs under 2.4)
The installation is now complete.
iv
