DATALOGIC
2.2 OPENING THE DEVICE
To install the C-BOX 200 or during normal maintenance, it is necessary to
open it by unscrewing the four cover screws:
The C-BOX 200 must be disconnected from the
power supply during this operation.
It is possible to perform the following operations:
Proceed with the cable connections (see paragraph 2.4.2).
Set the multiplexer address selection on the rotary switches.
Mount the C-BOX 200 to a wall or panel.
WARNING
Figure 2.2 - Opening the C-BOX 200
C-BOX 200
Installation - 3
