C-BOX 300/310
Installation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-BOX 300 and is the answer not in the manual?

Questions and answers

Related Manuals for Datalogic C-BOX 300

Summary of Contents for Datalogic C-BOX 300

  • Page 1 C-BOX 300/310 Installation Manual...
  • Page 3 C-BOX 300/310 INSTALLATION MANUAL...
  • Page 4 DATALOGIC S.p.A. Via Candini 2 40012 - Lippo di Calderara di Reno Bologna - Italy C-BOX 300/310 Ed.: 03/2006 ALL RIGHTS RESERVED Datalogic S.p.A. reserves the right to make modifications and improvements without prior notification. Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material.

  • Page 5: Table Of Contents

    Electrical Connections and Hardware Setup... 6 2.4.1 Power Supply... 7 2.4.2 System Wiring... 9 2.4.3 Scanner Chassis Grounding Jumper Settings ... 11 2.4.4 OM4000 Jumper Settings ... 11 Profibus Connections and Setup... 12 2.5.1 Profibus Node Address Selection ... 12 2.5.2...

  • Page 6: Guide To Installation

    2) Correctly position and mount the C-BOX 3X0 within the reach of the barcode scanner cable, according to the information in paragraph 2.3. 3) Provide correct system cabling according to the signals necessary for your application and PROFIBUS settings (see all sub-paragraphs under 2.4 and 2.5).

  • Page 7: General View

    GENERAL VIEW C-BOX 300 Figure A 25-pin scanner connector Compression connectors Cover screws (4) Profibus connector...
  • Page 8 C-BOX 310 Figure B LCD display Keypad...
  • Page 9 LCD contrast trimmer* Power on LED BUS activity LED Tx LED * For 310 models only C-BOX 300/310 Figure C - Cover Inside Module status LEDs Configuration switch Node address selectors Warning LED...
  • Page 10 Power on switch Scanner grounding selector Spring clamp terminal blocks GET button TEST button viii C-BOX 300/310 Figure D - Bottom Inside SEND button Auxiliary port connector OM4000 jumpers Warning LED 10 Power polarity error LED...

  • Page 11: Safety Precautions

    SAFETY PRECAUTIONS POWER SUPPLY ATTENTION: READ THIS INFORMATION BEFORE INSTALLING THE PRODUCT - This product is intended to be installed by Qualified Personnel only. The C-BOX 3X0 is intended to be supplied either by a UL Listed NEC Class 2 power source, or a UL Listed ITE Limited Power Source (LPS), rated 10-30 V dc, minimum 0.5 A.

  • Page 12: Weee Compliance

    Terminating Resistors Bus Connectors Cable Shield When connecting up the C-BOX 3X0, it is recommended to observe the guidelines in the VDE 0100 regulations for handling electrical equipment. WEEE COMPLIANCE Terminating resistors must be used if the C-BOX is installed at the beginning or end of the PROFIBUS cable segment.

  • Page 13: General Features

    In the C-BOX 310, visualize the data packet sent by the scanner on the LCD. The C-BOX 300 / C-BOX 310 mechanical dimensions are 167 x 115 x 61 mm (6.57 x 4.53 x 2.40 in.). The C-BOX 300 weighs about 440 g (15.50 oz); the C-BOX 310 weighs about 500 g (17.60 oz).

  • Page 14: Installation

    Verify that the C-BOX 3X0 and all the parts supplied with the equipment are present and intact when opening the packaging; the list of parts includes: C-BOX 3X0 Installation manual C-BOX 3X0 configuration CD-ROM 2 mounting screws Figure 1 - C-BOX 3X0 Package Contents C-BOX 300/310...

  • Page 15: Opening The Device

    INSTALLATION OPENING THE DEVICE To install the C-BOX 3X0 or during normal maintenance, it is necessary to open it by unscrewing the four cover screws: The C-BOX 3X0 must be disconnected from the power supply during this operation. CAUTION It is possible to perform the following operations: •...

  • Page 16: Mechanical Installation

    MECHANICAL INSTALLATION The diagram below gives the overall dimensions of the C-BOX 3X0 and may be used for its installation. Ø3 [Ø0.14] n°2 [5.91] [6.48] Figure 3 - Overall Dimensions C-BOX 300/310 [3.88] [4.53] inch...
  • Page 17 INSTALLATION C-BOX 3X0 can be installed to operate in different positions. The two screw holes inside the housing of the C-BOX 3X0 are for mechanical fixture (Figure 4). To mount the C-BOX 3X0: Open the C-BOX 3X0 by unscrewing the 4 cover screws. If necessary, using the two mounting holes inside the device as a pattern, mark the panel with an appropriate object and then drill two holes in the panel.

  • Page 18: Electrical Connections And Hardware Setup

    After making system cabling and switch settings (see sub-paragraphs under 2.4 and 2.5), connect the scanner to the 25-pin connector on the left side of the C-BOX 3X0 housing. Switch ON the C-BOX 3X0 power switch (see Figure 6).

  • Page 19: Power Supply

    Power is supplied to the C-BOX 3X0 through the pins provided on the spring clamp connector. The power switch (see Figure 6) switches the power supply ON or OFF for both the C-BOX 3X0 and the connected scanner. Figure 6 - Power Switch ON/OFF Positions C-BOX The power supply must be between 10 and 30 Vdc only.
  • Page 20 Make sure that the C-BOX is correctly grounded. WARNING The C-BOX 3X0 is protected against polarity reversal, a red LED signals this condition. When this condition occurs, all other C-BOX LEDs will be off until the power feed is connected with correct polarity. NOTE C-BOX 300/310...

  • Page 21: System Wiring

    INSTALLATION 2.4.2 System Wiring The connection and wiring procedure for C-BOX 3X0 is described as follows: Open the C-BOX 3X0 as described in paragraph 2.2. Verify that the C-BOX 3X0 power switch is off (see Figure 6). Unscrew the compression connectors and pass all the system cables through them into the C-BOX 3X0 housing.
  • Page 22 The C-BOX 3X0 spring clamp connector pinouts are indicated in the following table. Refer to the scanner Installation Manual for details. Name 1, 3, 5 2, 4, 6 7, 8 EARTH GROUND 9…12, 20, 33, 34, 40 Reserved OUT1+ OUT REF...

  • Page 23: Scanner Chassis Grounding Jumper Settings

    The scanner chassis grounding method can be selected by positioning a jumper (see Figure 9). In this way the scanner chassis can be connected to earth ground (only if pins 7 or 8 are connected to a good earth ground) or to the power supply ground signal.

  • Page 24: Profibus Connections And Setup

    To connect C-BOX 3X0 as a Profibus DP Slave, use a standard Siemens Profibus cable with a 9-pin male connector (see DIN 19245 part 1) and plug it into the 9-pin female external connector. HUNDREDS TENS UNITS Figure 11 - Rotary Switches C-BOX 300/310...

  • Page 25: Connection To A Profibus Network

    INSTALLATION 9-pin external female connector pinout Pin Name N.C. N.C. B-LINE + 5V (galvanically isolated) N.C. A-Line N.C. 2.5.3 Connection to a Profibus Network The following figure shows a Profibus layout with C-BOX 3X0 devices connected to a Profibus Master: PROFIBUS DP Master It is recommended to use only commercially available PROFIBUS connectors for...

  • Page 26: C-Box 3X0 Configuration For Profibus Dp Slave Node

    PROFIBUS network application as described in the configurator's Help On-Line or User's Manual. Further information on PROFIBUS protocol and Flow control is provided in the C-BOX 300/310 PROFIBUS document and Help On- Line installed from the configuration CD provided in the C-BOX package.

  • Page 27: Configuration Switch And 9-Pin Internal Connector

    Normal Operation (default): In this position, the C-BOX 3X0 is in the normal operating mode. It communicates with the scanner through the 9-pin internal connector and the scanner auxiliary serial interface. The internal connector pinout is illustrated in the following table:...
  • Page 28 CFG: When the switch is in this position, the C-BOX 3X0 is in configuration mode. The communication with the scanner is interrupted and pins 2 and 3 are no longer dedicated to the scanner auxiliary interface but to the C-BOX 3X0 configuration (see table below). The system enters configuration mode and waits to be configured through WinHost (see WinHost Help On Line).

  • Page 29: Scanner Requirements

    OFF), the C-BOX 3X0 is ready to receive code strings from the scanner's RS232 main interface. Then, it converts them to the Profibus DP network. GET/TEST/SEND: Through the C-BOX 300 internal buttons and the C-BOX 310 external keypad, it is possible to communicate with the scanner to perform one of the following functions: •...

  • Page 30: Get/Test/Send Functions

    2.8.1 GET/TEST/SEND Functions The C-BOX 300 has three internal function buttons. In the C-BOX 310, they are also available on the cover, and their function is indicated on the display. The GET/TEST/SEND function is not compatible with Matrix readers. NOTE The procedure to enable the GET/TEST/SEND function is the following: Press both the left and right buttons at the same time for at least one second;...
  • Page 31 Once the buttons are released in step 1, a ten-second timeout starts. If no button is pressed within this time (no function is selected), the procedure will be cancelled. The C-Box 300 warning LED (Figure 16) is turned OFF at the end of NOTE each procedure.

  • Page 32: Led Indicators

    C-BOX 300/310 2.8.2 LED Indicators Power on BUS activity TX LED MS LEDs Warning LED Figure 15 - LED Indicators In the C-BOX 3X0 the Warning LED is repeated in the bottom inside. Warning Power polarity error Figure 16 – Warning LED...
  • Page 33 INSTALLATION The internal LEDs of the C-BOX 3X0 (see Figure 15) indicate the following: POWER ON WARNING BUS ACTIVITY TRANSMISSION MODULE STATUS POWER POLARITY ERROR (red) indicates the C-BOX 3X0 is connected to the power supply and the power switch is ON. (red) indicates a warning or error condition.

  • Page 34: Special Notes For Matrix Reader Setup

    Select the Connect option to open communications with the C-BOX 3X0 and wait until the correct communication speed has been determined; From the SCANNER INTERFACE menu, set Auto Connect: Disabled and verify Data Source: Main Interface and save the configuration to the C-Box 3x0 (refer to Figure 17);...

  • Page 35: C-Box 3X0 Configuration For Matrix-1000™ Readers

    Select the Connect option to open communications with the C-BOX 3X0 and wait until the correct communication speed has been determined; From the SCANNER INTERFACE menu, set Data Source: Aux Interface and save the configuration to the C-Box 3x0 (refer to Figure 18);...
  • Page 36 C-BOX 300/310 Figure 18 – WinHost Configuration Menu for C-Box 3x0 Close the C-BOX 300.

  • Page 37: Technical Features

    Shock resistance IEC 68-2-27 test EA Protection class The features given are typical at a 25 not otherwise indicated). NOTE C-BOX 300 10 to 30 Vdc 2.9 W + scanner 4.7 W + scanner Power ON, Warning, Tx, Diagnostics 167 x 115 x 61 mm (6.57 x 4.53 x 2.40 in.) about 440 g.
  • Page 38 dichiara che declares that the déclare que le bescheinigt, daß das Gerät declare que el C-BOX-3X0 sono conformi alle Direttive del Consiglio Europeo sottoelencate: are in conformity with the requirements of the European Council Directives listed below: sont conformes aux spécifications des Directives de l'Union Européenne ci-dessous: der nachstehend angeführten Direktiven des Europäischen Rats: cumple con los requisitos de las Directivas del Consejo Europeo, según la lista siguiente: 89/336/EEC EMC Directive...
