Network Management Objects
CAUTION: Normally, most of the network management objects appear transparent to the
user. In other words, the parameters and objects used for network management are not normally
viewed or changed as part of device configuration.
The network management objects in the Logix 3400IQ digital positioner FBAP are listed in the
following paragraphs, although most, (if not all) of these objects are not directly user-configured.
Network Management Information Base (NMIB)
The NMIB contains various objects that are associated with network management operation. Table
8.28 lists the NMIB object dictionary. The groups of network management objects (along with
their index starting numbers) are included in the NMIB for the Logix 3400IQ digital positioner. The
numbers in parenthesis indicate the number of objects.

Table 8.28 Logix 3400IQ Digital Positioner NMIB Object Dictionary

Dictionary Index
Header
290
291
330
332
340
Not Used
337
337
Virtual Communications Reference (VCR) Objects
The objects listed above contain parameters which define network management operations. These
operations include communications between applications in different field devices (or field devices
and operator interface). In order for this communication to take place, a communications relationship
must be set up using the network management objects and parameters. The parameters for this
communication relationship are stored in a Virtual Communications Reference (VCR) object.
Logix 3400IQ Digital Positioner FCD LGENIM3402-00 – 0/07
Object
Reserved
Directory of Revision Number
Number of Directory Objects
Total Number of Directory Entries
Directory Index of First Composite List Reference
Number of Composite List References
Stack Management OD Index
Number of Objects in Stack Management (1)
VCR List OD Index
Number of Objects in VCR List (5)
DLL Basic OD Index
Number of Objects in DLL Basic (3)
DLL Link Master OD Index
Number of Objects in DLL Link Master (7)
Link Schedule OD Index
Number of Objects in Link Schedule
DLL Bridge OD Index
Number of Objects in DLL Bridge
Phy LME OD Index
Number of Objects in Phy LME (2)
Phy LME OD Index
Number of Objects in Phy LME (2)
