Flowserve Logix 3400IQ User Instructions page 79

Table 8.20 PID Block View Table
Index Name
50 HI_PRI
51 HI_LIM
52 LO_PRI
53 LO_LIM
54 LO_LO_PRI
55 LO_LO_LIM
56 DV_HI_PRI
57 DV_HI_LIM
58 DV_LO_PRI
59 DV_LO_LIM
60 HI_HI_ALM
61 HI_ALM
62 LO_ALM
63 LO_LO_ALM
64 DV_HI_ALM
65 DV_LO_ALM
Manufacturer Specific Parameters
66 PID_FORM
67 ALGO_TYPE
68 OUT_LAG
69 GAIN_NLIN
70 GAIN_COMP
71 ERROR_ABS
72 WSP
73 FUTURE1
74 BLOCK_TEST
Total
8.11 Alert Objects
Description
Alert objects support the reporting of alarms and update events to operator interface devices and
other field devices. Alert objects are used to communicate notification messages when alarms or
events are detected. These objects are defined in the function block application.
Alert objects contain:
• The value of the data
• Block index (a number)
• Alert key (parameter)
• Time stamp
• Priority
View1 View2
1
1
4
4
4
4
5
56 53
Logix 3400IQ Digital Positioner FCD LGENIM3402-00 – 0/07
View3 View4
1
4
1
4
1
4
1
4
1
4
4
4
5
8
104 104
7
