Section 5: Logix 3400Iq Digital Positioner Installation; Introduction; Mounting Variations; Figure 5.1 Typical Linear Actuator-Mounted Installation - Flowserve Logix 3400IQ User Instructions

5
Logix 3400IQ Digital Positioner
Installation

5.1 Introduction

About This Section
This section provides information about the mechanical and electrical installation of the Logix 3400IQ
digital positioner. It includes procedures for mounting, piping and wiring the Logix 3400IQ digital
positioner for operation. Refer to Logix 3400IQ Digital Positioner IOM in for detailed information.
5.2 Mounting Variations
Overview
The Logix 3400IQ digital positioner can be mounted to a:
• Valtek control valve
• Other manufacturer's control valve
NOTE: Figure 5.1 through Figure 5.4 show typical installations for comparison

Figure 5.1 Typical Linear Actuator-mounted Installation

Logix 3400IQ Digital Positioner FCD LGENIM3402-00 – 0/07
