Table 10.6 Error_Detail Parameter Enumeration; Table 10.7 Summary Of Configuration Errors - Flowserve Logix 3400IQ User Instructions

ERROR_DETAIL Enumeration
Table 10.6 lists the enumerated values for the error type element only. The location and sub-type
elements have no significant meaning for users.

Table 10.6 ERROR_DETAIL Parameter Enumeration

ERROR_DETAIL
0
1
2
3
4
5
6
7
8
9
10
11
Using ERROR_DETAIL for Troubleshooting
If a critical error occurs in the resource block, the user should read and record the ERROR_DETAIL
value. Then reset the device (write RESTART parameter Processor). Wait 30 seconds after reset and
read ERROR_DETAIL again to check if error cleared.
10.5 Block Configuration Errors
Configuration Errors
Block configuration errors prevent a device block from leaving OOS mode. The BLOCK_ERR
parameter (bit 1) shows whether a block configuration error is present. Table 10.7 summarizes the
conditions that may be the result of block configuration errors, which in turn cause a device fault.
Follow the recommended actions to correct these errors.

Table 10.7 Summary of Configuration Errors

Problem/Fault Probable Cause
Name of parameters Missing or incorrect version of device
are not visible description file on host computer.
Unable to write Mode not supported in TARGET and/or
successfully to PERMITTED modes for the given block.
MODE_BLK of any
block.
Unable to write to a 1. Parameter is read-only.
parameter
2. S ub-index of the parameter is read-only.
Some parameters have fields that are not
writable individually (such as MODE_BLK.
ACTUAL).
Logix 3400IQ Digital Positioner FCD LGENIM3402-00 – 0/07
Message
No error
Control board ROM checksum
HC16 boot ROM checksum
HC16 application ROM checksum
Interprocessor error (startup)
Interprocessor error (operation)
EEPROM corrupt (background diagnostics)
EEPROM driver error
EEPROM - fieldbus write
Sensor error
Internal software error
Other
Recommended Action
1. Check path to device description.
2. Load correct version of DD.
• V erify that the mode being written is
supported by the block.
• I f writing TARGET mode only, then the
desired mode must already be set in
the PERMITTED field.
• I f writing the whole MODE_BLK
record, then the mode set in TARGET
must also be set in the PERMITTED
field. Other modes may also be set in
the PERMITTED field, but target mode
must be set.
1. None
2. None
